Boss Elite

MPD500.1Monoblock Class D Amplifier

The Boss Elite MPD500.1 is organized here as a Monoblock Class D Amplifier for car audio power upgrades, with the main product role, controls, and core specs up front. Important details include Full Range Mono Class D Amplifier, 500 Watts Max, IP66-Rated (Dustproof/Weatherproof).

Highlights

Full Range Mono Class D Amplifier
500 Watts Max
IP66-Rated (Dustproof/Weatherproof)
Low Pass Filter

Key specs

Amp Topology: Monoblock, Class D
Power Supply Type: MOSFET Power Supply Watts
Total Power Output: 500 Watts
Peak Power @ 1 Ω: 500 Watts
Peak Power @ 2 Ω: 250 Watts
Peak Power @ 4 Ω: 125 Watts
RMS Power @ 1 Ω: 375 Watts
RMS Power @ 2 Ω: 188 Watts

Key specs

Amp Topology: Monoblock, Class D
Power Supply Type: MOSFET Power Supply Watts
Total Power Output: 500 Watts
Peak Power @ 1 Ω: 500 Watts

Highlights

Full Range Mono Class D Amplifier
500 Watts Max
IP66-Rated (Dustproof/Weatherproof)

Overview

Best for

Amplifiers - Mono
car audio power upgrades
Car audio upgrades
Powering multi-speaker car audio systems

Key points

Full Range Mono Class D Amplifier
500 Watts Max
IP66-Rated (Dustproof/Weatherproof)
Low Pass Filter
Bass Boost
RCA Level Inputs

Fit and use

Check the listed dimensions, connection options, and power ratings against the vehicle and system plan before ordering. The specification table keeps the source measurements and electrical details available for comparison.

What to know

This content is normalized from Boss Elite product data and Automob category/inventory data. Use the specs and manuals on the page for final confirmation before installation.

Highlights

Key features

Full Range Mono Class D Amplifier
500 Watts Max
IP66-Rated (Dustproof/Weatherproof)
Low Pass Filter
Bass Boost
RCA Level Inputs

More info

Full Range Mono Class D Amplifier
500 Watts Max
IP66-Rated (Dustproof/Weatherproof)
Low Pass Filter
Bass Boost
RCA Level Inputs
PWM MOSFET Power Supply
Remote Subwoofer Control
LED Illuminated End Panels
Thermal, Short and Overload Protection Circuits
Up to 500 Watts x 1CH RMS @ 1Ω
Up to 300 Watts x 1CH RMS @ 2Ω
Up to 180 Watts x 1CH RMS @ 4Ω

Specs

General Specs

Amp Topology	Monoblock, Class D
Power Supply Type	MOSFET Power Supply Watts

Performance Specs

Total Power Output	500 Watts
Peak Power @ 1 Ω	500 Watts
Peak Power @ 2 Ω	250 Watts
Peak Power @ 4 Ω	125 Watts
RMS Power @ 1 Ω	375 Watts
RMS Power @ 2 Ω	188 Watts
RMS Power @ 4 Ω	94 Watts
Speaker Impedance	1 to 8 Ω
T.H.D. (Total Harmonic Distortion)	0.01 %
Frequency Response	9 Hz to 50 kHz ±1 dB

Connections, Controls, and Processing

RCA Inputs	2 Channel
High Level Inputs	YES
Low Pass Filter	50 Hz
High-Pass Filter	Fixed
Subsonic Filter	15 Hz
Bass Boost	Variable
Subwoofer Level Control	YES
Input Sensitivity Switch	YES
Thermal/Overload/Short Protection	YES

Extra Features

SPECS_01

IP66-Rated (Dustproof Weatherproof)

Measurement

Length	7.8 "
Width	5.12 "

Additional Specs

Unit Weight lbs

3.48
