Boss Elite
BE10ACP.WX10.1-Inch Wireless CarPlay Multimedia Receiver
The Boss Elite BE10ACP.WX is organized here as a 10.1-Inch Wireless CarPlay Multimedia Receiver for in-dash receiver upgrades, with the main product role, controls, and core specs up front. Important details include 10.
Highlights
- 10.1” Capacitive Touchscreen
- Apple CarPlay® & Android Auto™ (Wired, Wireless)
- SiriusXM-Ready®
- iDatalink® Maestro Compatible
Key specs
Full specs- USB Port
- Front USB-C Rear USB-A
- A/V Input
- Rear
- Pre-Amp Outputs
- Front, Rear & Sub
- Total Power Output
- 340 Watts
- Steering Wheel Control (*Interface not included)
- YES
- Screen Size
- 10.1 "
- Touchscreen
- YES
- Resolution
- 1024
Key specs
Full specs- USB Port
- Front USB-C Rear USB-A
- A/V Input
- Rear
- Pre-Amp Outputs
- Front, Rear & Sub
- Total Power Output
- 340 Watts
Highlights
Overview- 10.1” Capacitive Touchscreen
- Apple CarPlay® & Android Auto™ (Wired, Wireless)
- SiriusXM-Ready®
Overview
The Boss Elite BE10ACP.WX is organized here as a 10.1-Inch Wireless CarPlay Multimedia Receiver for in-dash receiver upgrades, with the main product role, controls, and core specs up front. Important details include 10.1” Capacitive Touchscreen, Apple CarPlay® & Android Auto™ (Wired, Wireless), SiriusXM-Ready®.
Best for
- Source units upgrades
- in-dash receiver upgrades
- Car audio upgrades
- Replacing or upgrading an in-dash receiver
Key points
- 10.1” Capacitive Touchscreen
- Apple CarPlay® & Android Auto™ (Wired, Wireless)
- SiriusXM-Ready®
- iDatalink® Maestro Compatible
- Single-DIN Fit ( Double-DIN Adapter Brackets Included )
- Built-In DSP with 13-Band EQ, Crossover Settings and Time Alignment
Fit and use
Check the listed dimensions, connection options, and power ratings against the vehicle and system plan before ordering. The specification table keeps the source measurements and electrical details available for comparison.
What to know
This content is normalized from Boss Elite product data and Automob category/inventory data. Use the specs and manuals on the page for final confirmation before installation.
Highlights
Key features
- 10.1” Capacitive Touchscreen
- Apple CarPlay® & Android Auto™ (Wired, Wireless)
- SiriusXM-Ready®
- iDatalink® Maestro Compatible
- Single-DIN Fit ( Double-DIN Adapter Brackets Included )
- Built-In DSP with 13-Band EQ, Crossover Settings and Time Alignment
More info
- 10.1” Capacitive Touchscreen
- Apple CarPlay® & Android Auto™ (Wired, Wireless)
- SiriusXM-Ready®
- iDatalink® Maestro Compatible
- Single-DIN Fit ( Double-DIN Adapter Brackets Included )
- Built-In DSP with 13-Band EQ, Crossover Settings and Time Alignment
- High Resolution Audio Playback- FLAC
- Multicolor Illumination
- RDS/RBDS Tuner
- Switchable US/LATAM/EU Tuner Frequencies
- Built-in Programmable Steering Wheel Controls*
- Steering Wheel Interface Ready**
- Push-To-Talk
- *This unit is equipped with a programmable Steering Wheel Control Learning function for vehicles with analog steering control. Not compatible with all vehicles. **Steering Wheel Interface Ready (Interface sold separately).
Specs
Inputs & Outputs
3
| USB Port | Front USB-C Rear USB-A |
| A/V Input | Rear |
| Pre-Amp Outputs | Front, Rear & Sub |
Performance & Controls
2
| Total Power Output | 340 Watts |
| Steering Wheel Control (*Interface not included) | YES |
General
11
| Screen Size | 10.1 " |
| Touchscreen | YES |
| Resolution | 1024 |
| Switchable Tuner Frequencies | USA |
| RDS Tuner | YES |
| RBDS Tuner | YES |
| Tuner Preset | 10 FM |
| Selectable Preset EQ | Yes |
| ID3-Tag Information | Yes |
| Clock Display | Yes |
| Chassis Type | Single-DIN |
Mounting Measurement
3
| Width | 7.01 " |
| Height | 1.97 " |
| Depth | 4.94 " |
Extra Features
2
| SPECS_01 | Apple CarPlay and Android Auto are the smarter, safer way to use smart phone in your car. They seamlessly integrates your smart phone with the car’s built-in display and controls. Now you can make phone calls, access your music, send and receive messages, get directions, and more while you stay focused on the road. |
| SPECS_02 | Double-DIN Adapter Brackets included |
Additional Specs
4
| Unit Length In | 10.14 |
| Unit Width In | 10.28 |
| Unit Weight lbs | 4.59 |
| Qty Comes In Box | 1 |
