Rockford Fosgate P2002200 Watt 2-Channel Amplifier
The P2002 is a solid choice if you’re looking to drive coaxial speakers or a four-ohm SVC subwoofer. With proven Punch technology, the P2002 delivers real-world power without breaking the bank.
Highlights
- 1 Year Warranty
- Stealth Connections
- 4 Gauge power/ground connections with built-in ATC fusing
- Aux Ouputs
Key specs
Full specs- Number of Channels
- 2
- Total Power (Sum of Rated Power)
- 200 Watts RMS
- Rated Power (RMS Continuous Power)
- 50 Watts x 2 @ 4-Ohm 100 Watts x 2 @ 2-Ohm 200 Watts x 1 @ 4-Ohm Bridged
- Bridgeable
- Yes
- Frequency Response
- 20Hz to 20kHz +/- 0.5 dB
- Circuit Topology Class
- Class A/B
- Signal Input
- Low level: 1 RCA pair
- Signal Output
- Low level: 1 RCA pair
Key specs
Full specs- Number of Channels
- 2
- Total Power (Sum of Rated Power)
- 200 Watts RMS
- Rated Power (RMS Continuous Power)
- 50 Watts x 2 @ 4-Ohm 100 Watts x 2 @ 2-Ohm 200 Watts x 1 @ 4-Ohm Bridged
- Bridgeable
- Yes
Highlights
Overview- 1 Year Warranty
- Stealth Connections
- 4 Gauge power/ground connections with built-in ATC fusing
Overview
The P2002 is a solid choice if you’re looking to drive coaxial speakers or a four-ohm SVC subwoofer. With proven Punch technology, the P2002 delivers real-world power without breaking the bank.
Highlights
Key features
- 1 Year Warranty
- Stealth Connections
- 4 Gauge power/ground connections with built-in ATC fusing
- Aux Ouputs
- Focused mass heat sink allows critical aluminum material to be located around hottest internal devices
- RF Logo with Interactive Signal Display
- Thermal Sensing
- Connector Cover
- MEHSA
- TRANS•ana
- Balanced Differential Inputs
- NOMAD
More info
The P2002 is a solid choice if you’re looking to drive coaxial speakers or a four-ohm SVC subwoofer. With proven Punch technology, the P2002 delivers real-world power without breaking the bank.
Technologies
MEHSA
MEHSA (Maximum Efficiency Heat Sink Application) is a proprietary process that yields up to .ve times better heat
TRANS•ana
An award winning studio quality circuit borrowed from the pro audio company Hafler. TRANS-ana is a sound quality
Balanced Differential Inputs
Differential input circuitry measures the voltage of both the (+) and (-) input signal. The circuitry subtracts
NOMAD
NOMAD is a "real time" analog computer that protects your amplifier from shorting speaker wires and ...
TO-247 MOSFETs
The MOSFET transistor is the best type of device to use when building a high quality mobile amplifier. The Power
Engineered In The USA
[av• uh•tahr -noun] 1. an embodiment or personification, as of a principle, attitude, or view of life 2. a
Specs
Specifications
19
| Number of Channels | 2 |
| Total Power (Sum of Rated Power) | 200 Watts RMS |
| Rated Power (RMS Continuous Power) | 50 Watts x 2 @ 4-Ohm 100 Watts x 2 @ 2-Ohm 200 Watts x 1 @ 4-Ohm Bridged |
| Bridgeable | Yes |
| Frequency Response | 20Hz to 20kHz +/- 0.5 dB |
| Circuit Topology Class | Class A/B |
| Signal Input | Low level: 1 RCA pair |
| Signal Output | Low level: 1 RCA pair |
| Tone Controls | Bass: (see optional Accessories) |
| Crossover Controls | High-Pass (HP): 40-400Hz 12dB/octave Butterworth Low-Pass (LP): 40-400Hz 12dB/octave Butterworth |
| Remote Controls | Punch Bass EQ (see optional Accessories) |
| Visual Indicators | Power On Signal Level Thermal Status Speaker Protection |
| Power Wire Gauge | 4 AWG |
| Power Input Connector | Block |
| Speaker Wire Gauge | 8 AWG to 18 AWG |
| Speaker Output Connector | Screw terminal barrier strip |
| Cooling | Convection |
| Dimensions (H x W x D) | 2.4 x 11 x 11.7 (in) 6.1 x 27.9 x 29.7 (cm) |
| Shipping Weight | 11 Lbs. (4.9 Kg.) |
Reviews (0)
—
No average rating yet
0 reviews
No written reviews are live yet. Signed-in customers can submit one below.
No written reviews are live for this item yet.
Installation resources
Wiring diagrams
10
Wiring Diagram #1
Source: Rockford Fosgate
Wiring Diagram #2
Source: Rockford Fosgate
Wiring Diagram #3
Source: Rockford Fosgate
Wiring Diagram #4
Source: Rockford Fosgate
Wiring Diagram #5
Source: Rockford Fosgate
Wiring Diagram #6
Source: Rockford Fosgate
Wiring Diagram #7
Source: Rockford Fosgate
Wiring Diagram #8
Source: Rockford Fosgate
Wiring Diagram #9
Source: Rockford Fosgate
