Rockford Fosgate M2D2-12SM2 12" DVC 2Ω Color Optix™ Sealed Enclosure Marine Subwoofer
Variants
The Rockford Fosgate M2D2-12S is a 12" dual-voice-coil (DVC) 2‑ohm sealed enclosure marine subwoofer designed for marine environments.
Highlights
- 2-Year Warranty
- 100% UV Stable ASA plastic frame & grille design stands up to harsh marine environment
- VAST vertical attach surround technique increases effective radiating cone area up to 25%
- Klippel Verified certification program delivers the best possible loudspeakers
Key specs
Full specs- Size
- 12"
- Nominal Impedance (Ohms)
- 1-Ohm or 4-Ohm Switchable
- Power Handling (Watts RMS)
- 400 Watts RMS 1,600 Watts PEAK
- Voice Coil Type
- Dual Voice Coil
- Voice Coil Diameter
- 1.95" (49.53 mm)
- Magnet Weight (oz)
- 61.09 oz. (1.7 Kg)
- Frequency Response (Hz)
- 20 Hz - 750 Hz
- Fs (Hz)
- 32
Key specs
Full specs- Size
- 12"
- Nominal Impedance (Ohms)
- 1-Ohm or 4-Ohm Switchable
- Power Handling (Watts RMS)
- 400 Watts RMS 1,600 Watts PEAK
- Voice Coil Type
- Dual Voice Coil
Highlights
Overview- 2-Year Warranty
- 100% UV Stable ASA plastic frame & grille design stands up to harsh marine environment
- VAST vertical attach surround technique increases effective radiating cone area up to 25%
Overview
The Rockford Fosgate M2D2-12S is a 12" dual-voice-coil (DVC) 2‑ohm sealed enclosure marine subwoofer designed for marine environments. It combines a sealed-box subwoofer design with Color Optix™ lighting compatibility and Element Ready™ construction for use on boats and other watercraft.
Best for
- Small boats or marine craft with limited enclosure space
- Owners who want integrated, app-controllable lighting with their audio system
- Marine installations that require water- and UV-resistant components
Key points
- 12" DVC 2‑ohm sealed-enclosure subwoofer; sold individually (1 each)
- Color Optix™ lighting compatibility (Color Optix controller sold separately)
- Element Ready™ design for water, salt, and UV resistance
- Integrated Deutsch™ / Amphenol™ connectors for plug-and-play marine connectivity
- VERSA Switch™ lets you change impedance between 1 and 4 ohms
- IPX6 water intrusion rating and Klippel Verified performance
Fit and use
Designed to perform in small sealed enclosures where space is limited. The subwoofer is made to pair with the Rockford Fosgate Color Optix™ Controller and the RF Connect app via its integrated Deutsch/Amphenol connectors. Use with a compatible marine amplifier and the appropriate enclosure volume for sealed subwoofer designs.
What to know
Sold individually (1 each); additional items such as the Color Optix™ controller and app are sold separately. Multiple grille options are available, including a stainless-steel grille and sport grille inserts for a customized look. Product materials and testing (Element Ready™, IPX6, Klippel Verified, vibration testin…
Highlights
Key features
- 2-Year Warranty
- 100% UV Stable ASA plastic frame & grille design stands up to harsh marine environment
- VAST vertical attach surround technique increases effective radiating cone area up to 25%
- Klippel Verified certification program delivers the best possible loudspeakers
- Element Ready™ design protects lighting from exposure
- Bright, wide-angle LEDs provide rich, reliable illumination
- IPX6 Water Intrusion Rated
- Gold plated marine grade brass terminals provide a corrosion resistant connection
- Deutsch DT connectors incorporate front/rear silicone seals to protect against environmental ingress
- Provides superb low and midrange frequency reproduction with smooth high frequency roll-off
- Industry’s first molded in-frame connectors for simple connectivity in addition to conventional spade terminals
- Integrated Deutsch™/Amphenol™ connectors make wiring connections simple and error proof
More info
Manufacturer details
The M2D2-12S Color Optix™ 12” DVC 2-Ohm sealed enclosure subwoofers deliver loud, clear, accurate bass, and light the way for your journey! Sold individually (1 each).
Color Optix™: Adjust your own bright, wide, and limitless lighting experience with the Rockford Fosgate Color Optix™ plug-and-play controller (sold separately) and App.
Element Ready™: Purpose Built for the Marine Environment, Rockford’s Element Ready™ products are built to stand up to Water, Salt, and UV rays, making sure your subwoofers stand the test of time.
Grille Customization: Multiple grille options provides a customized look by using either the stainless-steel grille or the “sport” grille inserts, allowing you to dial in your personalized-on water experience.
True Marine Ecosystem: Integrated Deutsch™ / Amphenol™ connections provide industry leading marine plug-and-play connectivity and flexible install options.
Color Optix™: Requires PMX-RGB controller and RF Connect™ App
Color Optix™ Speakers | Launch
Color Optix™ Speakers | Overview
Color Optix™ Controller | Overview
Additional details
The M2 series of Element Ready™ subwoofers are designed to pair with the Rockford Fosgate Color Optix™ Controller and RF Connect App through its Deutsch™ and Amphenol™ connectors integrated into the basket. This combined with their IP67 certification make these speakers Element Ready™ and truly purpose built for marine applications. To compliment the plug and play connectivity and streamline installation, M2 subwoofers are equipped with a VersaSwitch™ to make changing impedance between 1 and 4 ohms as easy as flipping a switch. This subwoofer is designed to perform in small sealed designs when there is very little space for an enclosure.
Technologies
Color Optix™ Control
Adjust your own bright, wide, and limitless lighting experience with the Rockford Fosgate Color Optix™
VAST Surround - Marine
Rockford Fosgate's proprietary surround technique, VAST, provides up to a 25% increase in the speakers effective
VERSA Switch
Allows you to easily configure a 2Ω Dual Voice Coil subwoofer into 1Ω / 4Ω or a 4Ω DVC sub into 2Ω / 8Ω with the
True Marine Ecosystem
Dual Integrated Deutsch™ and Amphenol™ connections provide industry leading marine plug-and-play connectivity and
Element Ready™ | Subwoofers
All components are protected against harsh outdoor elements like Dust, UV, Temperature, Water, Corrosion &
ISO60068-2-64 Vibration Testing
ISO60068-2-64 Vibration testing standards ensure the product is durable and can withstand vibrations found on
Klippel Verified
To adorn the ‘Verified with Klippel’ mark, the qualifying company’s loudspeaker engineering personnel must be
IPX6 Water Intrusion Rated
A device with a level 6 water resistance rating can survive strong water jets projected by a 12.5mm nozzle at any
ASTM G154 Testing
ASTM G154 500Hr Accelerated UV testing
Showing the main technologies for this product.
Specs
Specifications
24
| Size | 12" |
| Nominal Impedance (Ohms) | 1-Ohm or 4-Ohm Switchable |
| Power Handling (Watts RMS) | 400 Watts RMS 1,600 Watts PEAK |
| Voice Coil Type | Dual Voice Coil |
| Voice Coil Diameter | 1.95" (49.53 mm) |
| Magnet Weight (oz) | 61.09 oz. (1.7 Kg) |
| Frequency Response (Hz) | 20 Hz - 750 Hz |
| Fs (Hz) | 32 |
| Re (Ohms) | 3.3 |
| Le (mH) | 3.43 |
| Sd (cm2) | 539 |
| Qms | 4.437 |
| Qes | 0.91 |
| Qts | 0.76 |
| Vas | 72 |
| SPL (dB @ 1w/1m) | 88 |
| SPL (dB @ 2.8v) | 89 |
| Xmax (mm) | 15 |
| Woofer Displacement | 0.121 (3.43 Liters) |
| Speaker Connector | 2-pin Deutsch™ and 1/8" Spade |
| Cutout Diameter | 11” (279.4 mm) |
| Mounting Depth | 4.87" (123.8 mm) |
| Shipping Weight | 10.64 Lbs. (4.83 Kg.) |
| Sealed Box Volume (Vb) | 0.75 (21 Liters) |
Reviews (0)
—
No average rating yet
0 reviews
No written reviews are live yet. Signed-in customers can submit one below.
No written reviews are live for this item yet.
Installation resources
Wiring diagrams
9
Wiring Diagram #1
Source: Rockford Fosgate
Wiring Diagram #2
Source: Rockford Fosgate
Wiring Diagram #3
Source: Rockford Fosgate
Wiring Diagram #4
Source: Rockford Fosgate
Wiring Diagram #5
Source: Rockford Fosgate
Wiring Diagram #6
Source: Rockford Fosgate
Wiring Diagram #7
Source: Rockford Fosgate
Wiring Diagram #8
Source: Rockford Fosgate
Wiring Diagram #9
Source: Rockford Fosgate
