Rockford Fosgate TMS24-696x9” 2-Way Element Ready Speakers for 2024+ Harley-Davidson (Gen-2)
Gen‑2 6x9-inch TMS saddlebag speakers from Rockford Fosgate are a high-output, element-ready 2-way design engineered to deliver stronger low-end and clearer mid/high response for on-bike audio.
Highlights
- Purpose Built for 2024+ factory H-D® ABS bags with HD24BL69
- 2-Year Warranty
- Upgrade for 1998-2013 factory H-D® ABS bags with TMS69BL9813
- Element Ready™ to withstand the harsh outdoor environment like dust, water, and UV rays
Key specs
Full specs- Midrange Size (Nominal Diameter)
- 6x9"
- Speaker Type
- 2-Way
- Nominal Impedance (Ohms)
- 4Ω
- Power Handling (MAX)
- 300 Watts
- Sensitivity (dB @ 1W/1M)
- 91.4 dB
- Voice Coil Diameter (in/mm)
- 1.5” (38.6 mm)
- Sensitivity (dB @ 1W/1M)
- 91.4 dB
- Voice Coil Diameter (in/mm)
- 1.5” (38.6 mm)
Key specs
Full specs- Midrange Size (Nominal Diameter)
- 6x9"
- Speaker Type
- 2-Way
- Nominal Impedance (Ohms)
- 4Ω
- Power Handling (MAX)
- 300 Watts
Highlights
Overview- Purpose Built for 2024+ factory H-D® ABS bags with HD24BL69
- 2-Year Warranty
- Upgrade for 1998-2013 factory H-D® ABS bags with TMS69BL9813
Overview
Gen‑2 6x9-inch TMS saddlebag speakers from Rockford Fosgate are a high-output, element-ready 2-way design engineered to deliver stronger low-end and clearer mid/high response for on-bike audio. They feature long-throw woofers, increased power handling, and environmental protection for motorcycle use.
Best for
- Owners of 2024+ Harley‑Davidson CVO Road Glide and CVO Street Glide (direct drop‑in fitment).
- Owners of 1998+ Harley‑Davidson models with an aftermarket Rockford Fosgate bag‑lid cut‑in kit.
- Riders who want higher output and deeper, more dynamic low-end from saddlebag speakers.
Key points
- Size: 6x9-inch, 2-way, element‑ready design.
- Power handling: up to 150 watts per speaker (Gen‑2).
- Acoustics: long‑throw woofers for extended low‑end and reduced distortion.
- Environmental protections: IPX6 water intrusion rating, dust resistant, UV inhibitor materials, corrosion protection.
- Performance verification and standards: Klippel Verified, ICC crossover, CTA‑2031 referenced.
- Packaging: sold in pairs; kit includes mounting hardware as specified by the manufacturer.
Fit and use
Direct drop‑in fitment for 2024+ CVO Road Glide and CVO Street Glide. For 1998+ Harley models, requires the Rockford Fosgate aftermarket bag‑lid cut‑in kit for direct fit. These are element‑ready 2‑way speakers intended as saddlebag replacements; confirm speaker opening and grille clearance for your bike before purchase.
What to know
Sold as a pair (two speakers). Rated to handle up to 150W per speaker—match amplifier output and settings to speaker ratings. Element‑ready means a 2‑way design prepared for added elements as supported by the system—check system compatibility before adding components. IPX6 rating indicates resistance to water intrusio…
Highlights
Key features
- Purpose Built for 2024+ factory H-D® ABS bags with HD24BL69
- 2-Year Warranty
- Upgrade for 1998-2013 factory H-D® ABS bags with TMS69BL9813
- Element Ready™ to withstand the harsh outdoor environment like dust, water, and UV rays
- Precision-tuned, long throw, high output design
- Extended frequency range for increased low-end response
- Integrated motor cover prevents valuables in saddle bag from heat damage
- Curvilinear poly cone with 10% carbon-fill for ideal stiffness and damping
- Santoprene® VAST surround resists dry rot and ensures long-lasting durability
- Breathable, durable Poly-Nomex spider resists moisture and wear
- UV-stable Domamid PA66 composite basket with reinforced 30% glass fiber
- Neodymium is up to 35% lighter and 65% smaller over traditional ferrite and ceramic
More info
Manufacturer details
The next generation of TMS motorcycle speakers revolutionizes on-bike audio with unparalleled sound quality. Engineered for the ultimate listening experience, they deliver a perfectly balanced sound profile; enhanced mids, powerful bass, and ultra-clear highs. Crafted from premium materials, these speakers set a new standard for performance, durability and reliability for the motorcycle environment. Sold in pairs (2 each).
Precision-Tuned: Featuring long-throw woofers for high output and deep, extended low-end response, these speakers deliver powerful yet balanced sound. The large voice coil and extended frequency range enhance bass output, ensuring louder, more dynamic, and long-lasting performance.
Performance Engineered: Each element of these speakers is meticulously engineered for peak performance. Now handling up to 150 watts each — twice the power of before — these speakers feature a heat-resistant motor structure and radiator ring to efficiently dissipate heat, ensuring consistent, powerful sound even under the most demanding conditions.
Direct Fitment: Designed for a seamless upgrade, these speakers offer a direct drop-in fit for factory mounting locations.
Element Ready™: Purpose built for the harsh motorcycle environment. The speakers are designed to stand up to water, dirt, UV, and motorcycle vibration, ensuring that your audio will stand the test of time.
Compatibility Chart: Please review below tab for fitment before purchasing.
2024+ TMS24-69 | Launch
2024+ TMS24-69 | Overview
2024+ TMS24-69 | Installation (jumps to 28:11)
Additional details
Loud. Clear. Relentless.
Engineered for performance and precision, the 2nd generation TMS 6x9” saddlebag speaker is a long-throw, high-output design with an extended low-end response and reduced distortion for a richer, more balanced listening experience. It features direct drop-in fitment for 2024+ Harley-Davidson® CVO Road Glide and CVO Street Glide, and direct fitment for 1998+ Harley-Davidson® models equipped with an aftermarket Rockford Fosgate bag-lid cut-in kit.
Kit Includes:
• (2) 6x9” TMS 2.0 speakers
• Mounting hardware
Technologies
Dust Resistant
Displays and motor structures are sealed tight so they look and sound as clear as possible no matter how many
Klippel Verified
To adorn the ‘Verified with Klippel’ mark, the qualifying company’s loudspeaker engineering personnel must be
ICC Crossover
The Integrated Concealed Crossover hides the crossover inside the basket, creating a cleaner look and easier
CTA-2031
Power handling on Rockford Fosgate speakers conform to CTA-2031 industry standards. This means your speaker has
UV Inhibitor Materials
Centrex and ASA plastic materials are used for their UV radiation resistance and components are tested in
Water Resistant
IPX Ratings allow for the components to be directly sprayed with water without ingress.
IPX6 Water Intrusion Rating
A device with a level 6 water resistance rating can survive strong water jets projected by a 12.5mm nozzle at any
Corrosion Protection
Components are tested for salt spray corrosion resistance.
Vibration Resistant
Components are able to withstand shock and vibration conditions common with outdoor vehicles.
Showing the main technologies for this product.
Specs
Specifications
13
| Midrange Size (Nominal Diameter) | 6x9" |
| Speaker Type | 2-Way |
| Nominal Impedance (Ohms) | 4Ω |
| Power Handling (MAX) | 300 Watts |
| Sensitivity (dB @ 1W/1M) | 91.4 dB |
| Voice Coil Diameter (in/mm) | 1.5” (38.6 mm) |
| Sensitivity (dB @ 1W/1M) | 91.4 dB |
| Voice Coil Diameter (in/mm) | 1.5” (38.6 mm) |
| Crossover | 4 kHz @ 12dB/Octave |
| Mounting Hardware | Yes |
| Grille/Trim Ring Included | No |
| In The Box | (1 pr) TMS24-69 Speaker 1130-80766-01 AP Pack • (8) Phillips Tapping Screws, M4x1.4, 15.5mm |
| Shipping Weight | 7 Lbs. (3.18 Kg) |
Reviews (0)
—
No average rating yet
0 reviews
No written reviews are live yet. Signed-in customers can submit one below.
No written reviews are live for this item yet.
Support
Return Authorization
If you bought this product from Onkar Electronics, use the Contact Us page on the Onkar Electronics website and we will help with return authorization and warranty support. If you purchased it from another dealer, contact that authorized dealer first for return assistance.
Popular Questions
No FAQs available
Compatibility
REQUIREDSkyline™ OS |
YESH-D® ABS Saddlebags3 |
YESH-D® Power Lock2 |
YESH-D® 6x9" Speaker Lids3 |
NOT RECOMMENDEDDon't mix TMS with Stage I/I/III) |
|---|
YESCompatible with factory equipment |
POSSIBLECan fit with required items below |
NOModel NOT compatible with kit |
NOT AVAILABLEModel not produced this year |
|---|
YES |
2024+ | HD24BL69 | 6x9" Saddlebag Cut-In Speaker Kit for 2024+ Harley-Davidson | |
YES |
2024+ | HD24-STG3 | Stage-3 Audio Kit for 2024+ Harley-Davidson | |
NO |
2014 — 2023 | HD14-SBSUB | Dual 10" Saddlebag Subwoofer Kit for 2014-2023 Harley-Davidson Street Glide & Road Glide | |
NO |
2014 — 2023 | HD14-STG5 | Stage-5 Speaker & Amp Kit for 2014-2023 Harley-Davidson Street Glide & Road Glide | |
NO |
2014 — 2023 | HD14-PMX-STG5 | Stage-5 Complete Kit for 2014-2023 Harley-Davidson Street Glide & Road Glide | |
YES |
2014 — 2023 | TMS69BL14 | Saddlebag Kit for 2014+ Harley-Davidson Models | |
YES |
2014 — 2023 | HD14RK-STAGE2 | 2-Speaker & Amp Kit for 2014+ Road King | |
YES |
2014 — 2023 | HD14-STG3 | Stage-3 Speaker & Amp Kit for 2014-2023 Harley-Davidson Street Glide & Road Glide | |
YES |
2014 — 2023 | HD14-PMX-STG3 | Stage-3 Complete Kit for 2014-2023 Harley-Davidson Street Glide & Road Glide® | |
YES |
1998 — 2013 | TMS69BL9813 | Saddlebag Audio Kit for 1998-2013 Harley-Davidson Models | |
YES |
1998 — 2013 | HD9813RK-STAGE2 | 2-Speaker & Amp Kit for 1998-2013 Road King | |
YES |
1998 — 2013 | HD9813RG-STG3 | Stage-3 Speaker & Amp Kit for 1998-2013 Harley-Davidson Road Glide | |
YES |
1998 — 2013 | HD9813SG-STG3 | Stage-3 Speaker & Amp Kit for 1998-2013 Harley-Davidson Street Glide & Electra Glide |
| MODEL | CHASSIS | 2023 | 2024 | 2025 |
|---|---|---|---|---|
| Road Glide® | FLTRX | X | ✓ | ✓ |
| Road Glide® ST | FLTRXST | X | — | — |
| Road Glide® Special | FLTRXS | X | — | — |
| Road Glide® Special 120th Anniversary | FLTRXSANV | X | — | — |
| Street Glide® | FLHX | X | ✓ | ✓ |
| Street Glide® ST | FLHXST | X | — | — |
| Street Glide® Special | FLHXS | X | — | — |
| Street Glide® Special 120th Anniversary | FLHXSANV | X | — | — |
| MODEL | CHASSIS | 2023 | 2024 | 2025 |
|---|---|---|---|---|
| Electra Glide Highway King | FLHFB | X | — | — |
| Road King® Special | FLHRXS | X | X | X |
| MODEL | CHASSIS | 2023 | 2024 | 2025 |
|---|---|---|---|---|
| Road Glide® Limited | FLTRK | X | X | — |
| Street Glide® Ultra | FLHXU | — | — | ✓ |
| Ultra Limited | FLHTK | X | X | — |
| Ultra Limited 120th Anniversary | FLHTKANV | X | — | — |
| Ultra Limited Shrine Edition | FLHTK | X | — | — |
| MODEL | CHASSIS | 2023 | 2024 | 2025 |
|---|---|---|---|---|
| CVO Road Glide® | FLTRXSE | ✅SKY2 | ✅SKY2 | ✅SKY2 |
| CVO™ Road Glide® RR | FLTRXRRSE | — | — | ✓ |
| CVO Road Glide® ST | FLTRSXTSE | — | ✅SKY2 | ✅SKY2 |
| CVO Road Glide® Limited 120th Anniversary | FLTRKSEANV | XRF1 | — | — |
| CVO Street Glide® | FLHXSE | ✅SKY2 | ✅SKY2 | ✅SKY2 |
| MODEL | CHASSIS | 2023 | 2024 | 2025 |
|---|---|---|---|---|
| Freewheeler® | FLRT | XNR | XNR | XNR |
| Road Glide 3 | FLTRT | X | X | X |
| Tri Glide® Ultra Classic® | FLHTCUTG | X | X | X |
| Tri Glide® Ultra 120th Anniversary | FLHTCUTGANV | X | — | — |
GRAY TEXT
indicates nomenclature used on some early models and later inherited.
2
H-D® Power Lock on factory Harley-Davidson bags are compatible.
3
Saddlebags must be factory Harley-Davidson® ABS plastic to insure proper fitment with bag-lid and subwoofer kits.
Fiberglass saddlebags and lids are not compatible. Color matched speaker lids are not compatible.
4
Stretched Saddlebags not optimized for kits with subwoofers. Contact technical support for suggested harness brace.
5
Tour-Pak® must be detached in order to install and remove subwoofer enclosures.
NR
No Radio equipped from factory.
RF1
RF Stage I: Not upgradable. Factory equipped with "Harley-Davidson Audio Powered by Rockford Fosgate" 2-way speakers and saddlebag amplifier.
RF2
RF Stage II: Not upgradable. Factory equipped with "Harley-Davidson Audio Powered by Rockford Fosgate" 3-way speakers and saddlebag amplifier.
SKY1
Skyline RF Stage I: Factory equipped with Skyline OS and "Harley-Davidson Audio Powered by Rockford Fosgate" 2-way speakers and 500W primary amplifier.
This system replaces and is not designed to be used with factory equipped audio.
Models with factory Harley-Davidson® Saddlebag Speaker Lids will also require TMS24-69 speakers.
SKY2
Skyline RF Stage II: Factory equipped with Skyline OS and "Harley-Davidson Audio Powered by Rockford Fosgate" 3-way speakers and 500W primary amplifier.
This system replaces and is not designed to be used with factory equipped audio.
Models with factory Harley-Davidson® Saddlebag Speaker Lids will also require TMS24-69 speakers.
SKY3
Skyline RF Stage III: Factory equipped with Skyline OS and "Harley-Davidson Audio Powered by Rockford Fosgate" 3-way high-output speakers and 500W primary amplifier.
This system replaces and is not designed to be used with factory equipped audio.
Models with factory Harley-Davidson® Saddlebag Speaker Lids will also require TMS24-69 speakers.
