The DSR1 combines a full-featured 3Sixty digital signal processor with an integrated, flashable iDatalink Maestro module. It accepts high- or low-level inputs immediately, or can be flashed with vehicle-specific firmware to preserve factory controls and features.
Buyer confidence
88%Highlights
- Digital Signal Processing with Integrated Maestro CAN Interface
- Optional PLC2 Level Controller with Assignable Functions
- Four Channel High Level Inputs with Signal Sense Turn On
- 18 Pin Analog Input Harness
Key specs
Full specs- Processor Type
- Digital Processor
- Signal Input
- 4 Balanced Differential RCA Inputs 4 High-Level Inputs w/ Signal Sense 2 AUX RCA Inputs SPDIF Coaxial Input
- Signal Output
- 8 RCA Outputs
- Gain
- —
- Output Impedance
- 200 Ohms
- Frequency Response
- 20Hz - 20kHz +/- 0.5dB
- Operating Voltage
- 9 - 16 VDC
- Mounting
- Behind Dash
Key specs
Full specs- Processor Type
- Digital Processor
- Signal Input
- 4 Balanced Differential RCA Inputs 4 High-Level Inputs w/ Signal Sense 2 AUX RCA Inputs SPDIF Coaxial Input
- Signal Output
- 8 RCA Outputs
- Gain
- —
Overview
The DSR1 combines a full-featured 3Sixty digital signal processor with an integrated, flashable iDatalink Maestro module. It accepts high- or low-level inputs immediately, or can be flashed with vehicle-specific firmware to preserve factory controls and features. Tuning and sound-profile adjustments are done through Rockford Fosgate’s PerfectTune app.
Best for
- Integrating aftermarket processing while retaining factory source unit controls
- Replacing factory amplifier and speakers in compatible Ford and Chrysler vehicles
- Installers and enthusiasts who want app-based tuning via Apple or Android devices
- Systems that require both high- and low-level input compatibility
Key points
- 8-channel interactive digital signal processor based on Rockford Fosgate 3Sixty platform
- Integrated, flashable iDatalink Maestro module for vehicle-specific firmware and integration
- Out-of-the-box operation with high- or low-level inputs
- Allows retention of factory controls and features after flashing vehicle firmware
- Tuning and adjustments via Rockford Fosgate PerfectTune app (iOS and Android)
- Uses the full-range, flat audio signal from factory source units for certain Ford and Chrysler integrations
Fit and use
The DSR1 is designed to be added between the factory source unit and the rest of the audio system. It can be used immediately with high- or low-level inputs, or flashed with vehicle-specific Maestro firmware to enable CANbus-based control and internal signal routing. Final sound tuning is performed with the PerfectTune app; software and updater utilities are available from the manufacturer.
What to know
Flashing the Maestro module with the correct vehicle-specific firmware enables preservation of factory controls and full integration; without the flash, the unit still accepts high- and low-level inputs. Use the PerfectTune app and the manufacturer's updater utility for tuning and firmware updates. Consult the product…
Highlights
Key features
- Digital Signal Processing with Integrated Maestro CAN Interface
- Optional PLC2 Level Controller with Assignable Functions
- Four Channel High Level Inputs with Signal Sense Turn On
- 18 Pin Analog Input Harness
- 16 Pin Analog Output Harness
- Micro USB Setup/Update Port
- Designed for use with Select Maestro Vehicle T-Harnesses
- Auxiliary RCA and SPDIF Coaxial Inputs
- 245 Bands of Equalization for Aftermarket Tuning
- Adjustable crossovers with selectable slope
- Up 10msec of delay on each channel for Time Alignment
- CE and FCC Compliant
More info
Manufacturer details
Co-developed with iDatalink Maestro, the DSR1 combines a full-featured 3Sixty digital signal processor with a flashable Maestro integration module. The DSR1 can be used out-of-the-box with high or low level input, or with a quick flash download to add vehicle specific firmware to enable integration without the loss of factory equipped controls and features. Once connected, complete control of the sound profile can be adjusted using the proprietary Rockford Fosgate PerfectTune™ software.
DSR1 | Software Downloads
DSR1 | Updater Utility
Download PerfectTune™ to control the DSR1:
Additional details
The DSR1 is the first real solution for replacing the factory amplifier and speakers in Ford and Chrysler vehicles, as the DSR1 uses the full-range, flat audio signal from the factory source unit.
After the built-in Maestro interface is flashed with the vehicle-specific firmware, the factory source unit CANbus messages are used to control the internal signal routing of the DSR1. The DSR1 still utilizes the power processor found in our patented 3Sixty.3, but adds an easy to use app for tuning from Apple and Android devices.
Technologies
Tuning Connectivity via Bluetooth
Bluetooth connectivity allows connection to a mobile device for tuning (non audio streaming.)
DSM
DSM - An industry-leading manufacturing process, DSM utilizes high-speed robotics, high-quality 1% tight-tolerance
CE Compliant
This product fulfills all essential safety and environmental requirements as defined in the European Directives
iDatalink Maestro
The iDatalink Maestro technology is a flashable module that allows vehicle specific firmware to be downloaded to
Specs
Specifications
25
| Processor Type | Digital Processor |
| Signal Input | 4 Balanced Differential RCA Inputs 4 High-Level Inputs w/ Signal Sense 2 AUX RCA Inputs SPDIF Coaxial Input |
| Signal Output | 8 RCA Outputs |
| Gain | — |
| Output Impedance | 200 Ohms |
| Frequency Response | 20Hz - 20kHz +/- 0.5dB |
| Operating Voltage | 9 - 16 VDC |
| Mounting | Behind Dash |
| Input Voltage | Low Level (RCA): up to 4V High Level: up to 12.5V High Level Turn-On: 4V - 16V AUX: up to 2V |
| Output Voltage | up to 4V RMS |
| THD+N | <1.0% |
| Signal-to-Noise | RCA: >100 dBA (A-weighted) AUX: >100 dBA (A-weighted) |
| THD+N | <1.0% |
| Signal-to-Noise | RCA: >100 dBA (A-weighted) AUX: >100 dBA (A-weighted) |
| Crossover Type | High-Pass Low-Pass Band-Pass All-Pass Fixed Linkwitz-Riley |
| Smartphone App | App Store Google Play |
| Smartphone Compatibility | APPLE: iOS 10.0 or later (iPhone, iPad, iPod touch) ANDROID: Oreo 8.0 or later (optimized for 5-inch screen or larger) |
| Analog to Digital (ADC) | Precision: 24-Bit Dynamic Range: 105 dB THD+N: -98 dB |
| Digital to Analog (DAC) | Precision: 24-Bit Dynamic Range: 108 dB THD+N: -98 dB |
| Crossover Frequency | Variable: 20 Hz to 10 kHz |
| Crossover Slope | Selectable Slope: 6/12/18/24/30/36/48 dB/Octave |
| EQ Frequency Centers | Channels: Front/Spare/Rear/Sub Frequency Bands: 31 per channel |
| EQ Frequency Controls | Selectable Q: 0.01 to 10.0 |
| Shipping Weight | 0.5 Lbs. (0.22 Kg) |
| Dimensions (H x W x D) | 1.26" x 4.04" x 5.12" (32 mm x 102.5 mm x 130 mm) |
Reviews (0)
—
No average rating yet
0 reviews
No written reviews are live yet. Signed-in customers can submit one below.
No written reviews are live for this item yet.
Support
Return Authorization
If you bought this product from Onkar Electronics, use the Contact Us page on the Onkar Electronics website and we will help with return authorization and warranty support. If you purchased it from another dealer, contact that authorized dealer first for return assistance.
Popular Questions
Mobile device cannot recognize DSR1
by Eric Russell
· 2 months ago
· Updated
My PerfectTune app will not find the DSR1. How can I fix this?
This issue is commonly found on Android Phones and Android Tablets. If the Rockford Fosgate PerfectTune app cannot find the DSR1, please check to make sure the "Location" settings on the Android device are tuned "ON". Depending on the device you can access the "Location" option in "Personal Settings" or "Google" option in settings.
Download RF Connect™ to control the DSR1:
|
|
|
Compatibility
The DSR1 is flexible enough to be operated in Universal Mode or Maestro Mode:
• Universal Mode requires RCA or High-Level inputs and aftermarket amplifier(s).
• Maestro Mode requires vehicle specific T-harness (see below) and aftermarket amplifier(s).
• Universal Mode requires RCA or High-Level inputs and aftermarket amplifier(s).
• Maestro Mode requires vehicle specific T-harness (see below) and aftermarket amplifier(s).
OEM SYSTEM: WITH FACTORY AMP
| Harness | Vehicle Make(s) | Vehicle Coverage | Description |
|---|---|---|---|
| HRN-AR-FO2 | Ford | iDataLink Vehicle Coverage | Amplifier replacement T-harness for select Ford vehicles with 8-inch "My Ford Touch" radio and Sony Amplified system 2011 and up. |
| HRN-AR-FO3 | Ford | iDataLink Vehicle Coverage | Amplifier replacement T-harness for select Ford Mustang trims 2015 and up. |
| HRN-AR-CH2 | Chrysler Dodge Jeep RAM Volkswagen |
iDataLink Vehicle Coverage | Amplifier replacement T-harness for select Chrysler, Dodge, Fiat, Jeep, Ram and Volkswagen vehicles 2007 and up. |
| HRN-AR-CH3 | Chrysler Dodge Fiat Jeep |
iDataLink Vehicle Coverage | Amplifier replacement T-harness for select select Chrysler, Dodge, Fiat and Jeep 2012 and up. |
| HRN-AR-CH4 | Chrysler Dodge Jeep Maserati RAM |
iDataLink Vehicle Coverage | Amplifier replacement T-harness for select Chrysler, Dodge, Jeep, Maserati and Ram vehicles 2016 and up. |
| HRN-AR-TO1 | Lexus Toyota |
iDataLink Vehicle Coverage | Amplifier replacement T-harness for select Lexus and Toyota vehicles 2008 and up. |
| HRN-AR-TO2 | Lexus Subaru Toyota |
iDataLink Vehicle Coverage | Amplifier replacement T-harness for select Toyota, Lexus and Subaru vehicles 2012 and up. |
| HRN-AR-TO3 | Subaru Toyota |
iDataLink Vehicle Coverage | Amplifier replacement T-harness for select Toyota and Subaru vehicles 2005 and up. |
OEM SYSTEM: NO FACTORY AMP
| Harness | Vehicle Make(s) | Vehicle Coverage | Description |
|---|---|---|---|
| HRN-DSP-CH3 | Chrysler Dodge Fiat Jeep RAM |
iDataLink Vehicle Coverage | DSP installation T-harness for select Chrysler, Dodge, Fiat, Jeep and Ram vehicles 2013 and up without factory amplifiers. |
| HRN-DSP-NI1 | Chevrolet infiniti Nissan Subaru |
iDataLink Vehicle Coverage | DSP installation T-harness for select Inifiniti, Nissan and Subaru vehicles without factory amplifiers. |
| HRN-DSP-TO1 | Scion Subaru Toyota |
iDataLink Vehicle Coverage | T-Harness for select Scion, Subaru and Toyota vehicles without factory amplifiers. |
EXTENSION CABLES
| Harness | Vehicle Make(s) | Vehicle Coverage | Description |
|---|---|---|---|
| HRN-AR-EXT2 | Chrysler Dodge Ford Jeep Lexus Maserati RAM Subaru Toyota |
iDataLink Vehicle Coverage | 2-meter amplifier relocation extension harness. |
| HRN-AR-EXT4 | Chrysler Dodge Ford Jeep Lexus Maserati RAM Subaru Toyota |
iDataLink Vehicle Coverage | 4-meter amplifier relocation extension harness. |
Videos
Maestro for DSR1
An overview of the Maestro module inside DSR1 that allows you to interface with factory installed systems equipped with a factory amplifier.
