Memphis Audio

Memphis Audio MM5004VMM Series Marine Grade Amplififiers By Memphis Were

MM Series marine grade amplififiers by Memphis were designed to withstand the water and the elements. These amplififiers feature sealed chassis and conformal coated boards which allows them to perform in the harshest marine environment.

Highlights

  • IPX5 rated
  • Removable power terminal
  • Sealed removable signal connectors
  • Sealed top mount controls

Key specs

Full specs
RMS POWER 4Ω
80 x 4
RMS POWER 2Ω
125 x 4
RMS POWER 1Ω
BRIDGED/MONO POWER 4Ω
250 x 2
THD% 4Ω
<1%
FREQ RESPONSE
10Hz – 25kHz
DIMENSIONS L xW x H
10.5 x 7.3 x 2
INPUT RANGE
200 mV – 20 V

Key specs

Full specs
RMS POWER 4Ω
80 x 4
RMS POWER 2Ω
125 x 4
RMS POWER 1Ω
BRIDGED/MONO POWER 4Ω
250 x 2

Highlights

Overview
  • IPX5 rated
  • Removable power terminal
  • Sealed removable signal connectors
Overview
MM Series marine grade amplififiers by Memphis were designed to withstand the water and the elements. These amplififiers feature sealed chassis and conformal coated boards which allows them to perform in the harshest marine environment. These amplififiers feature loads of upgrades geared towards making them the most installer-friendly marine amp ever produced by Memphis. Single sided terminals, removable power lug, sealed outputs with waterproof quick-disconnects and sealed top mounted control panel all make this amplififier extremely durable and user friendly. With 2/4/6 channel options, this is the most complete Marine amp lineup in Memphis history allowing for system desing from simple to extreme.
Highlights

Key features

  • IPX5 rated
  • Removable power terminal
  • Sealed removable signal connectors
  • Sealed top mount controls
  • Extruded aluminum heat sink
  • Signal sensing auto turn on
  • 12dB/octave butterworth crossovers
  • Input select switch
  • LED light strip
  • Protection circuitry against:
  • Overload, short circuit, thermal &amp; reverse polarity
  • Variable bass boost (0-12dB) centered at 45Hz
Specs

Specifications

9
RMS POWER 4Ω80 x 4
RMS POWER 2Ω125 x 4
RMS POWER 1Ω
BRIDGED/MONO POWER 4Ω250 x 2
THD% 4Ω<1%
FREQ RESPONSE10Hz – 25kHz
DIMENSIONS L xW x H10.5 x 7.3 x 2
INPUT RANGE200 mV – 20 V
AMP KIT8GKIT
