Hertz

#VENEZIA V4C

Hertz VENEZIA V4CCompact Marine Amplifier

Venezia V4C compact marine amplifier features an optimized power/size ratio boosting 110 W x 4 (4Ω) and 380 W x 2 (4Ω)! Hertz Advanced Class D technology maximizes efficiency and power while minimizing heat and electromagnetic radiation - enhancing sound quality that reaches new...

Highlights

  • Engineered and tested for marine application (UV, salt-fog, vibrations, high/low temperature, thermal shock) featuring IPX2 certification.
  • ADC (Advanced D-Class) Technology 2Ω (1Ω for mono models) stable output stage providing Hi-Res certified audio performance with superior efficiency.
  • Die-cast aluminum compact design with fan-less convection cooling system ensuring low operating temperature even at maximum power.
  • Balanced fully-differential input circuitry to reject electromagnetic disturbances.

Key specs

Full specs
Channels
4 - 3 - 2
Power supply voltage
9 ÷ 16 VDC
ldling current (power ON/OFF):
1 A / 0.04 mA
Consumption@ 2Ω, 14.4 VDC (Max Musical Power):
21 A
Remote In:
7 ÷ 15 VDC - 1 mA
Distorsion - THD (100Hz @ 4Ω):
<0,06%
Bandwidth:
10 ÷ 42 kHz
S/N Ratlo (A welghted @ 1 V):
102 dB

Key specs

Full specs
Channels
4 - 3 - 2
Power supply voltage
9 ÷ 16 VDC
ldling current (power ON/OFF):
1 A / 0.04 mA
Consumption@ 2Ω, 14.4 VDC (Max Musical Power):
21 A

Highlights

Overview
  • Engineered and tested for marine application (UV, salt-fog, vibrations, high/low temperature, thermal shock) featuring IPX2 certification.
  • ADC (Advanced D-Class) Technology 2Ω (1Ω for mono models) stable output stage providing Hi-Res certified audio performance with superior efficiency.
  • Die-cast aluminum compact design with fan-less convection cooling system ensuring low operating temperature even at maximum power.
Overview
Venezia V4C compact marine amplifier features an optimized power/size ratio boosting 110 W x 4 (4Ω) and 380 W x 2 (4Ω)! Hertz Advanced Class D technology maximizes efficiency and power while minimizing heat and electromagnetic radiation - enhancing sound quality that reaches new highs with Hi-Res certification! High-powered channels with bridging capability deliver the output levels needed in the marine environment. Venezia V4C is engineered and tested for marine applications (UV, salt-fog, vibrations, high/low temperature, thermal shock) and has obtained the IPX2 certification. The Safe-Lock Input, Output, and Power connections streamline installation and enhance durability in the field. The fanless convection cooling system is integrated into the cast heat-sink chassis. The balanced fully-differential input circuitry rejects electromagnetic noise and interference. The powerful and flexible preamp filter options are far beyond most mobile amplifier capabilities. Last but not least, Venezia V4C is fully protected by short-circuit, overload, and thermal protections - with auto-resetting.
Highlights

Key features

  • Engineered and tested for marine application (UV, salt-fog, vibrations, high/low temperature, thermal shock) featuring IPX2 certification.
  • ADC (Advanced D-Class) Technology 2Ω (1Ω for mono models) stable output stage providing Hi-Res certified audio performance with superior efficiency.
  • Die-cast aluminum compact design with fan-less convection cooling system ensuring low operating temperature even at maximum power.
  • Balanced fully-differential input circuitry to reject electromagnetic disturbances.
  • Bridge operation mode to drive a subwoofer or to create a powerful dual-mono system.
  • Built-in filter section protected by a polycarbonate panel suitable for any system configuration.
  • Short-circuit, overload, and thermal protections with auto-resetting.
  • Plug&Play Input and Output connections with safe-lock.
  • Proprietary Plug&Play Power Supply Connector with safe-lock.
  • ADC
  • Hi-Res
  • CORROSION RESISTANT
Technologies
ADC

ADC

Hertz Advanced Class D architecture maximizes efficiency and power while minimizing heat and electromagnetic

Hi-Res

Hi-Res

Hi-Res certified performance, with an extended audio band up to 40 kHz.

CORROSION RESISTANT

CORROSION RESISTANT

Electronics components corrosion caused by exposure in wet environments is totally neutralized by the use of

SALT FOG TESTED

SALT FOG TESTED

To satisfy the standards required by ASTM-B117, Hertz Marine products are tested with massive salt fog spray to

WATER JET RESISTANT

WATER JET RESISTANT

This Hertz Marine amplifier is IPX2 certified when installed vertically with connections facing downward.

Specs

General Specs

13
Channels4 - 3 - 2
Power supply voltage9 ÷ 16 VDC
ldling current (power ON/OFF):1 A / 0.04 mA
Consumption@ 2Ω, 14.4 VDC (Max Musical Power):21 A
Remote In:7 ÷ 15 VDC - 1 mA
Distorsion - THD (100Hz @ 4Ω):<0,06%
Bandwidth:10 ÷ 42 kHz
S/N Ratlo (A welghted @ 1 V):102 dB
Damping factor (100Hz @ 4Ω)150
Pre-ln sensitivity:0.2 ÷ 5 VRMS
Load impedance (MIN) @4Ch: @3Ch: @2Ch:2 Ω + 2 Ω + 4 Ω 2 Ω 4 Ω
Weight (kg/lb):2.62 / 5.77
Adjustable Crossoversyes

Output Power

6
4Ch110 W x 4 (4Ω)
4Ch190 W x 4 (2Ω)
3Ch110 W x 2 (4Ω) + 380 W x 1 (4Ω)
3Ch190 W x 2 (2Ω) + 380 W x 1 (4Ω)
2Ch380 W x 2 (4Ω)
Total Power760 W

INPUTS / FILTERS

11
lnputs:PRE IN
Pre Out FULL range (FRONT)Yes
FRONT Ch. filters FULL:Yes
Hi-Pass :50 ÷ 4k Hz @ dB/Oct
Lo-Pass:50 ÷ 4k Hz @ dB/Oct
REAR Ch. filters FULL:Yes
Hi-Pass:50 ÷ 4k Hz @ dB/Oct
Lo-Pass:50 ÷ 4k Hz @ dB/Oct
FRONT Ch. MONO (on/off):Yes
REAR Ch. MONO (on/off):Yes
BOOST 50 Hz (adjust):(0 ÷ 12) dB

Physical Specs

6
VENEZIA V4C
mmin
A205 | 8.07
B175 | 6.88
C155 | 6.1
D125 | 4.92
E40.5 | 1.59
