Hertz

#CAPRI HBB

Hertz CAPRI HBBBlack Box Version Of The Renowned Hertz CAPRI Marine Source

The CAPRI HBB is the black box version of the renowned Hertz CAPRI marine source, delivering the same high-resolution audio performance and advanced features without an integrated display.

Highlights

Native DSP working at 24 bit/96 kHz and an extended audio band up to 40 kHz for hi-res audio performance.
CAPRI BB is designed to play 24-bit/96 kHz hi-res audio for audiophile sound.
CAPRI BB features 4 pairs of stereo outputs each with independent subwoofer output providing the ability to create 4 independently controlled listening areas to obtain the perfect sound everywhere.
The powerful 8-band digital equalizer will support you in finding the best sound.

Key specs

PEAK POWER @ 4 Ω: CLASS-D: 4 x 70 W
FRONT PANEL IP RATING: IP66
MULTI-ZONE: 4
LINE OUT (RCA): 4x L+R (one per zone) - HPF: ALL, 60, 80, 100 Hz
SUBWOOFER OUT (RCA): 4x (LPF: ALL, 60, 80, 100 Hz)
AUX INPUT (RCA): 2x L+R
S/PDIF DIGITAL IN: Toslink (24 bit/96 kHz)
A2B® DIGITAL BUS: UTP cable (24 bit/96 kHz)

Key specs

PEAK POWER @ 4 Ω: CLASS-D: 4 x 70 W
FRONT PANEL IP RATING: IP66
MULTI-ZONE: 4
LINE OUT (RCA): 4x L+R (one per zone) - HPF: ALL, 60, 80, 100 Hz

Highlights

Native DSP working at 24 bit/96 kHz and an extended audio band up to 40 kHz for hi-res audio performance.
CAPRI BB is designed to play 24-bit/96 kHz hi-res audio for audiophile sound.
CAPRI BB features 4 pairs of stereo outputs each with independent subwoofer output providing the ability to create 4 independently controlled listening areas to obtain the perfect sound everywhere.

Overview

The CAPRI HBB is the black box version of the renowned Hertz CAPRI marine source, delivering the same high-resolution audio performance and advanced features without an integrated display. Designed for seamless control via remote units, Bluetooth® app, or NMEA 2000®, it ensures full management of four independent zones with dedicated subwoofer outputs. Engineered to withstand harsh marine environments, the CAPRI HBB offers superior connectivity, including Bluetooth® 5.1, USB, digital inputs/outputs, and DAB+ readiness, for an audiophile-grade marine experience.

Highlights

Key features

Native DSP working at 24 bit/96 kHz and an extended audio band up to 40 kHz for hi-res audio performance.
CAPRI BB is designed to play 24-bit/96 kHz hi-res audio for audiophile sound.
CAPRI BB features 4 pairs of stereo outputs each with independent subwoofer output providing the ability to create 4 independently controlled listening areas to obtain the perfect sound everywhere.
The powerful 8-band digital equalizer will support you in finding the best sound.
Customize the sound with 8 EQ presets created by Hertz audio engineer.
Voltage indicator to check battery status.

Specs

Specification

PEAK POWER @ 4 Ω	CLASS-D: 4 x 70 W
FRONT PANEL IP RATING	IP66
MULTI-ZONE	4
LINE OUT (RCA)	4x L+R (one per zone) - HPF: ALL, 60, 80, 100 Hz
SUBWOOFER OUT (RCA)	4x (LPF: ALL, 60, 80, 100 Hz)
AUX INPUT (RCA)	2x L+R
S/PDIF DIGITAL IN	Toslink (24 bit/96 kHz)
A2B® DIGITAL BUS	UTP cable (24 bit/96 kHz)
S/PDIF DIGITAL OUT	Coaxial (24 bit/96 kHz)
EQUALIZER	CUSTOM 8 BANDS for each zone
EQ. PRESET	8
CAMERA IN	Yes
BATTERY VOLTAGE GAUGE	Yes

Sources

TUNER	AM/FM (RDS) (EU/US) Weather band
USB	Yes (2A)
IPOD/IPHONE	Yes
DAB+	Ready
SIRIUSXM READY	Yes
BLUETOOTH	5.1 Audio streaming with ID3 Tag Display LDAC – AAC – APTX HD
REMOTE CONTROL	HMC HD1 (up to 4 zones) HMC U1 (up to 2 zones)

Size & Mounting

Unit Size mm (in.)	W 146 (5.748) x H 105 (4.134) x D 121 (4.763)
Mounting Hole size mm (in.)	W 122 (4.8) x H 52 (2.05)
Mounting Depth mm (in.)	99 (3.89
Mounting Method	Panel mount (4 screws)

Physical Specs

A	197 - 7.76 (mm - in.)
A1	173 - 6.81 (mm - in.)
A2	197 - 7.76 (mm - in.)
B	150.65 - 5.93 (mm - in.)
B1	56 - 2.2 (mm - in.)
C	50 - 1.97 (mm - in.)
D	5 - 0.2 (mm - in.)

Reviews (0)

—

No average rating yet

0 reviews

No written reviews are live yet. Signed-in customers can submit one below.

Own this product?

Share installation notes, sound quality feedback, and fitment tips. Customer reviews are saved in the same database and go live after moderation.

No written reviews are live for this item yet.

Support

Downloads

Owner's Manual

Accessories

CAPRI HD1

SKU: CAPRI HD1

HD1 provides the ability to replicate every function of the CAPRI HBB main unit, creating up to 3 independently controlled listening areas.

HMC NMEA2K

SKU: HMC NMEA2K

Enhance your marine audio experience with the HMC NMEA2K Volume Control, designed for seamless integration with your NMEA 2000® network.

HMC U1

SKU: HMC U1

WATER SPORT READY Play your favorite song and pump up the volume while swimming in open water. Thanks to IPX7 certification you can install HMC U1 remote control freely anywhere on the boat, adding fun to every cruise.

CAPRI HMB DAB+

This module add DAB+ DIGITAL RADIO capability. Provided with dedicated antenna.

CAPRI HMA C13Y

SKU: CAPRI HMA C13Y

Optional for connecting CAPRI HD1 to CAPRI HBB main unit
