Cerwin Vega

Cerwin Vega VCU81VEGA Series 1-Channel Class-D Mono Block Amplifier

VCU81 - VEGA Series 1-Channel Class-D Mono Block Amplifier Vega Series Amplifiers – Compact Design, Monstrous Power The Vega Series Amplifiers have solidified their place as the backbone of the Cerwin-Vega Mobile brand, delivering unrivaled performance in a sleek, compact...

Highlights

  • Updated High-Efficiency Full Range Digital Topology: Experience exceptional sound clarity with maximum energy efficiency.
  • Enhanced Power IR Digital Chipset: Engineered for stability and precision, ensuring consistent performance under any condition.
  • Conformal-Coated 4-Layer PCB: Protected against moisture and environmental wear for long-lasting reliability.
  • Water-Resistant Design: Built to withstand the rigors of the road, wherever your journey takes you.

Key specs

Full specs
FREQUENCY RESPONSE (HZ)
40HZ - 400HZ
RMS POWER PER CHANNEL 4Ω
175W x 1
RMS POWER PER CHANNEL 2Ω
300W x 1
RMS POWER PER CHANNEL RMS 1Ω
500W
Power Supply
Full PWM
Power Supply Threshold
10.0V-17.0V (DC)
Idle Current
(0.7A)
THD 4 (1KHz @4Ω)
0.05%

Key specs

Full specs
FREQUENCY RESPONSE (HZ)
40HZ - 400HZ
RMS POWER PER CHANNEL 4Ω
175W x 1
RMS POWER PER CHANNEL 2Ω
300W x 1
RMS POWER PER CHANNEL RMS 1Ω
500W

Highlights

Overview
  • Updated High-Efficiency Full Range Digital Topology: Experience exceptional sound clarity with maximum energy efficiency.
  • Enhanced Power IR Digital Chipset: Engineered for stability and precision, ensuring consistent performance under any condition.
  • Conformal-Coated 4-Layer PCB: Protected against moisture and environmental wear for long-lasting reliability.
Overview

VCU81 - VEGA Series 1-Channel Class-D Mono Block Amplifier

Vega Series Amplifiers – Compact Design, Monstrous Power

The Vega Series Amplifiers have solidified their place as the backbone of the Cerwin-Vega Mobile brand, delivering unrivaled performance in a sleek, compact package. Don’t be deceived by their streamlined design—these amplifiers pack a punch with monstrous power output to drive your system to its fullest potential.

Innovation Meets Power

  • Updated High-Efficiency Full Range Digital Topology: Experience exceptional sound clarity with maximum energy efficiency.
  • Enhanced Power IR Digital Chipset: Engineered for stability and precision, ensuring consistent performance under any condition.

Engineered for Durability

  • Conformal-Coated 4-Layer PCB: Protected against moisture and environmental wear for long-lasting reliability.
  • Water-Resistant Design: Built to withstand the rigors of the road, wherever your journey takes you.

Unmatched Versatility

  • Remote Turn-On Configurator (REM/DC/VOX): Simplifies integration with any audio system.
  • Accepts Hi and Lo-Level Inputs Up to 12V: Seamlessly connects to your existing setup, no matter the source.
  • Boosted RFI Rejection: Keeps your sound crystal-clear, free from interference.

Compact Design, Big Impact

The matching heatsink platform dimensions ensure a consistent, stylish look while optimizing thermal management for uninterrupted performance.

Why Choose Vega?

Whether you’re a seasoned audio enthusiast or just starting to elevate your system, the Vega Series Amplifiers offer a balance of design, durability, and performance that’s hard to beat. From pounding bass to crystal-clear highs, these amps are the powerhouse your system deserves.

The Vega Legacy

With Cerwin-Vega’s unmatched legacy of audio innovation and more than 65 years of expertise, the Vega Series Amplifiers continue to define what’s possible in mobile sound systems.

Compact. Powerful. Reliable. Elevate your audio experience with Vega Series Amplifiers.

Highlights

Key features

  • Updated High-Efficiency Full Range Digital Topology: Experience exceptional sound clarity with maximum energy efficiency.
  • Enhanced Power IR Digital Chipset: Engineered for stability and precision, ensuring consistent performance under any condition.
  • Conformal-Coated 4-Layer PCB: Protected against moisture and environmental wear for long-lasting reliability.
  • Water-Resistant Design: Built to withstand the rigors of the road, wherever your journey takes you.
  • Remote Turn-On Configurator (REM/DC/VOX): Simplifies integration with any audio system.
  • Accepts Hi and Lo-Level Inputs Up to 12V: Seamlessly connects to your existing setup, no matter the source.
  • Boosted RFI Rejection: Keeps your sound crystal-clear, free from interference.
Specs

Specifications

22
FREQUENCY RESPONSE (HZ)40HZ - 400HZ
RMS POWER PER CHANNEL 4Ω175W x 1
RMS POWER PER CHANNEL 2Ω300W x 1
RMS POWER PER CHANNEL RMS 1Ω500W
Power SupplyFull PWM
Power Supply Threshold10.0V-17.0V (DC)
Idle Current(0.7A)
THD 4 (1KHz @4Ω)0.05%
S/N Ratio (A weighted @1W)-85 dBA
S/N Ratio (A weighted @FP)-101.1 dBA
Low Input Level200mV-10.0V
High Input Level200mV-10.0V
Low Input Level20 KΩ
High Input Level20 KΩ
Output Impedance0.011Ω
Damping Factor (50Hz @ 4Ω)>250
Bandwidth (-3dB)10Hz-35KHz
Variable Low-Pass40Hz-400Hz
Variable Sub-Sonic10Hz-55Hz
ATC25A
L x W x H7.7”x 4.02”x 1.4” (195.6mm x 102mm x 36mm)
MFR #VCU81
