Cerwin Vega
Cerwin Vega B55B55 - Stealth Bomber 5-Channel Class-D Full Range Amplifier
Variants
B55 - Stealth Bomber 5-Channel Class-D Full Range Amplifier Cerwin-Vega Mobile Stealth Bomber Series Amplifiers – Compact. Powerful. Revolutionary.
Highlights
- Updated High-Efficiency Full-Range Digital Topology: Delivers unparalleled sound clarity with maximum energy efficiency.
- Class D IR Chipset with Direct-FET Power MOSFET Output: Ensures precision and performance for every beat.
- Ultra-Compact High-Density Aluminum Alloy Chassis: Offers robust protection and optimal heat dissipation in a sleek form factor.
- Advanced Rollback Power/Thermal Protection: Keeps your system running at peak performance, even under the most demanding conditions.
Key specs
Full specs- FREQUENCY RESPONSE (HZ)
- 70HZ-20KHZ
- RMS POWER PER CHANNEL 4Ω 80W X 4 &
- 200W x 1
- RMS POWER PER CHANNEL 2Ω 150W X 4 &
- 350W x 1
- RMS POWER PER 2 CHANNELS BRIDGED 4Ω 300W X 2 &
- 200W x 1
- Power Supply
- Full PWM
- Power Supply Threshold
- 10.0V-17.0V (DC)
- Idle Current
- (0.7A)
- THD 4 (1KHz @4Ω)
- 0.5%
Key specs
Full specs- FREQUENCY RESPONSE (HZ)
- 70HZ-20KHZ
- RMS POWER PER CHANNEL 4Ω 80W X 4 &
- 200W x 1
- RMS POWER PER CHANNEL 2Ω 150W X 4 &
- 350W x 1
- RMS POWER PER 2 CHANNELS BRIDGED 4Ω 300W X 2 &
- 200W x 1
Highlights
Overview- Updated High-Efficiency Full-Range Digital Topology: Delivers unparalleled sound clarity with maximum energy efficiency.
- Class D IR Chipset with Direct-FET Power MOSFET Output: Ensures precision and performance for every beat.
- Ultra-Compact High-Density Aluminum Alloy Chassis: Offers robust protection and optimal heat dissipation in a sleek form factor.
Overview
B55 - Stealth Bomber 5-Channel Class-D Full Range Amplifier
Cerwin-Vega Mobile Stealth Bomber Series Amplifiers – Compact. Powerful. Revolutionary.
The Stealth Bomber Series Amplifiers embody the perfect fusion of sleek design and unmatched power, making them a cornerstone of the Cerwin-Vega Mobile lineup. Designed for seamless integration, these ultra-compact amplifiers are proof that big sound can come in small packages.
High-Tech Innovation Meets Raw Power
- Updated High-Efficiency Full-Range Digital Topology: Delivers unparalleled sound clarity with maximum energy efficiency.
- Class D IR Chipset with Direct-FET Power MOSFET Output: Ensures precision and performance for every beat.
Built for Durability and Precision
- Ultra-Compact High-Density Aluminum Alloy Chassis: Offers robust protection and optimal heat dissipation in a sleek form factor.
- Advanced Rollback Power/Thermal Protection: Keeps your system running at peak performance, even under the most demanding conditions.
Versatility at Your Fingertips
- Switchable 12dB HP/FLAT/LP Crossovers: Tailor your audio experience with precise control over high-pass, low-pass, or flat outputs.
- VEGA Bass Boost: Elevate your low-end frequencies with a dynamic bass enhancement feature.
- Remote Turn-On Configurator (REM/DC/VOX): Simplifies integration with a variety of systems for effortless operation.
Why Choose Stealth Bomber?
The Stealth Bomber Series Amplifiers pack monstrous power into a compact design, making them the ideal choice for enthusiasts seeking an efficient, space-saving solution without compromising performance. Perfect for tight installations, these amps are engineered to deliver clean, distortion-free sound with explosive bass and dynamic clarity.
Performance That Soars Above the Rest
With Cerwin-Vega Mobile’s legacy of innovation and expertise, the Stealth Bomber Series is your ultimate audio companion for maximum impact in any vehicle.
Unleash the power. Command the clarity. Take your sound system to new heights with the Stealth Bomber Series.
Highlights
Key features
- Updated High-Efficiency Full-Range Digital Topology: Delivers unparalleled sound clarity with maximum energy efficiency.
- Class D IR Chipset with Direct-FET Power MOSFET Output: Ensures precision and performance for every beat.
- Ultra-Compact High-Density Aluminum Alloy Chassis: Offers robust protection and optimal heat dissipation in a sleek form factor.
- Advanced Rollback Power/Thermal Protection: Keeps your system running at peak performance, even under the most demanding conditions.
- Switchable 12dB HP/FLAT/LP Crossovers: Tailor your audio experience with precise control over high-pass, low-pass, or flat outputs.
- VEGA Bass Boost: Elevate your low-end frequencies with a dynamic bass enhancement feature.
- Remote Turn-On Configurator (REM/DC/VOX): Simplifies integration with a variety of systems for effortless operation.
Specs
Specifications
22
| FREQUENCY RESPONSE (HZ) | 70HZ-20KHZ |
| RMS POWER PER CHANNEL 4Ω 80W X 4 & | 200W x 1 |
| RMS POWER PER CHANNEL 2Ω 150W X 4 & | 350W x 1 |
| RMS POWER PER 2 CHANNELS BRIDGED 4Ω 300W X 2 & | 200W x 1 |
| Power Supply | Full PWM |
| Power Supply Threshold | 10.0V-17.0V (DC) |
| Idle Current | (0.7A) |
| THD 4 (1KHz @4Ω) | 0.5% |
| S/N Ratio (A weighted @1W) | -85 dBA |
| S/N Ratio (A weighted @FP) | -101.1 dBA |
| Low Input Level | 200mV-10.0V |
| High Input Level | 200mV-10.0V |
| Low Input Level | 20 KΩ |
| High Input Level | 20 KΩ |
| Output Impedance | 0.018Ω |
| Damping Factor (50Hz @ 4Ω) | >70 |
| Bandwidth (-3dB) | 10Hz-35Hz |
| Variable High-Pass | Flat or Fixed 70Hz |
| Variable Low-Pass | 40Hz-400Hz |
| ATC | 60A |
| L x W x H | 10.45”x 4.02”x 1.4” (265.6mm x 102mm x 36mm) |
| MFR # | B55 |
