Rockford Fosgate 20GLADR-STG51,800 Watt All-In-One Audio Kit for Select 2020-2023 Jeep Gladiator JT
High-output 1,800 watt all-in-one audio system engineered for select 2020–2023 Jeep Gladiator JT. Plug-and-play design with Jeep-specific DSP tuning and Element Ready™ durability.
Highlights
- Durable PE (Poly Ethylene) material with friction welded seams
- 2-Year Warranty
- Nearly 2x louder than premium audio system
- Plug-and-Play design for easy installation
Key specs
Full specs- Total Power
- 1,800 Watts
- Amplifiers
- (1) M5-800X4 (1) M5-1000X1
- Fuse Size
- 150 ANL
- Accessory Pack
- (1) ABS Drill Template for Jeep (3) Flat Washer M4-0.7, 9mm OD, 1mm TH (20) Nylon Cable Tie 0.17 x 8 in. (3) Stamped Clip (1) 12V Socket Removal Tool for Jeep Wrangler (1) Hole Saw with Arbor, 20mm Diameter (3) Large Screw, M4x0.7, x 8mm (3) Thread Forming Screw, 1/4-14 THD, 0.75 in L, Hex, 0.375 (1) Drill Bit, 4.76mm Diameter, 89mm L (2) Flat Flange Washer 2.5mm (1) Subwoofer Bracket Passenger (1) Subwoofer Bracket Driver (1) Machine Screw, M5, 16mm, Hex (1) SHCS Screw, M5x0.8, 30mm L, Hex, 4mm (2) Coupling Nut, M6x1, 10mm Diam., 20mm L (2) SHCS Screw, M6x1, 45mm L, Hex, 5mm (4) FHCS Screw, M6x1, 10mm L, Hex, 4mm (1) Nylon Nut, M5x0.8, 8mm Hex, 5mm Tall (1) Steel-Neoprene Sealing Washer (2) Clipped Washer, 5.3 ID, 16.0 OD
- Front Speakers
- (2) M2-TS (2) TMS65
- Soundbar Speakers
- (2) TMS65
- Subwoofers
- (2) T1S2-10
- Shipping Dimensions
- 23.1” x 28.1” x 55.9” 58.7 cm x 71.5 cm x 14.20 cm
Key specs
Full specs- Total Power
- 1,800 Watts
- Amplifiers
- (1) M5-800X4 (1) M5-1000X1
- Fuse Size
- 150 ANL
- Accessory Pack
- (1) ABS Drill Template for Jeep (3) Flat Washer M4-0.7, 9mm OD, 1mm TH (20) Nylon Cable Tie 0.17 x 8 in. (3) Stamped Clip (1) 12V Socket Removal Tool for Jeep Wrangler (1) Hole Saw with Arbor, 20mm Diameter (3) Large Screw, M4x0.7, x 8mm (3) Thread Forming Screw, 1/4-14 THD, 0.75 in L, Hex, 0.375 (1) Drill Bit, 4.76mm Diameter, 89mm L (2) Flat Flange Washer 2.5mm (1) Subwoofer Bracket Passenger (1) Subwoofer Bracket Driver (1) Machine Screw, M5, 16mm, Hex (1) SHCS Screw, M5x0.8, 30mm L, Hex, 4mm (2) Coupling Nut, M6x1, 10mm Diam., 20mm L (2) SHCS Screw, M6x1, 45mm L, Hex, 5mm (4) FHCS Screw, M6x1, 10mm L, Hex, 4mm (1) Nylon Nut, M5x0.8, 8mm Hex, 5mm Tall (1) Steel-Neoprene Sealing Washer (2) Clipped Washer, 5.3 ID, 16.0 OD
Highlights
Overview- Durable PE (Poly Ethylene) material with friction welded seams
- 2-Year Warranty
- Nearly 2x louder than premium audio system
Overview
High-output 1,800 watt all-in-one audio system engineered for select 2020–2023 Jeep Gladiator JT. Plug-and-play design with Jeep-specific DSP tuning and Element Ready™ durability.
Best for
- Jeep Gladiator JT owners (select 2020–2023) who want a factory-integrated
- high-output audio upgrade built for off-road use and tuned specifically for the vehicle.
Key points
- Total system power: 1,800 watts.
- Includes (from product data): two T1S2-10 dual 10" subwoofers with enclosure.
- Front and overhead TMS65 6.5" coaxial speakers with enclosures.
- Two M2-TS 1" dash tweeters with bezels.
- Two amplifiers: M5-1000X1 (1,000W) and M5-800X4 (800W), both pre-tuned.
- Integrated Digital Signal Processor (DSP) with a Jeep-specific tune using a custom 6-microphone array.
Fit and use
Designed to integrate with the Gladiator JT factory interior and electrical system via a plug-and-play wiring kit. Pre-tuned amps and a vehicle-specific DSP tune are provided to deliver a calibrated listening experience; on-vehicle bass adjustment is available via the included PLC2 control.
What to know
This kit is developed specifically for select 2020–2023 Jeep Gladiator JT applications. Rockford Fosgate provides a programming and tuning guide and additional advisory documentation for vehicle-specific tuning and setup. Installation time and procedures vary by installer and vehicle condition.
Highlights
Key features
- Durable PE (Poly Ethylene) material with friction welded seams
- 2-Year Warranty
- Nearly 2x louder than premium audio system
- Plug-and-Play design for easy installation
- Direct bolt into vehicle using OEM mounting holes
- High output performance
- Integrated OEM style enclosures w/ factory connectors
- T-harness integration eliminates cutting or splicing wires
- Minimal cutting (for models that require 12v accessory relocation only)
- Audio integration into OEM CAN-bus system
- DSP recognition with auto-loading Jeep Gladiator specific tune
- Custom bass level control matches OEM dash and controls
More info
Manufacturer details
The Gladiator Stage 5 Jeep all-in-one audio kit was developed to take your 4×4 adventure to the next level. This 1,800 watt plug and play audio kit delivers high output performance; a jeep specific tune to ensure an epic listening experience as well as a straightforward installation. The system is designed and engineered to match and compliment your factory interior and was built Element Ready™ ensuring lasting performance no matter the terrain.
Performance Sound: With a total of 1,800 watts, this audio kit is equipped with two 10" subwoofers, front and overhead 6.5" coaxial speakers, front 1-inch tweeters, and both a 1,000-watt and an 800-watt amplifier that are pre-tuned. The kit also features a Digital Signal Processor with a specific Jeep tune, all to ensure the best-in-class listening experience.
Element Ready™: Purpose built for the off-road environment, Rockford’s Element Ready™ products are built to stand up to water, dirt, mud and UV rays, making sure all your audio components perform regardless of the conditions.
Plug-and-Play Design: With the Plug and Play wire harnesses, OEM style enclosures with factory connectors, and no cutting wires or plastic parts you will enjoy an easy and simple installation process.
RF3 (Rockford Factory Fit and Finish): Designed and engineered to match and compliment the factory fit and finish of your vehicle. These components are purpose built to the exact specifications to ensure the best-in-class fitment and look.
Compatibility Chart: Please review below tab for fitment before purchasing.
2020+ Gladiator Stage-5 | Launch
2020+ Gladiator Stage-5 | Overview
2020+ Gladiator Stage-5 | Installation
2020+ Gladiator Stage-5 | Programming & Tuning Guide
Additional details
Where Sound Meets Adventure
The Jeep Gladiator Stage 5 is an all-in-one 1,800 Watt high-performance audio system that’s 4x louder than the base audio and nearly 2x louder than the premium audio system. It stands apart from the competition with its fully integrated Digital Signal Processor tuned specifically for Jeep Gladiator by Rockford Fosgate engineers using a custom designed 6-microphone array.
Components
(2) M2-TS M2 1” Dash Tweeters + Bezels
(2) TMS65 6.5” Front Speakers + Enclosures
(2) TMS65 6.5” Overhead Speakers + Enclosure
(2) T1S2-10 Dual 10” Subwoofers + Enclosure
(1) DSP + Jeep Specific Tune
(1) M5-800X4 800 Watt Amp + Jeep Specific Tune
(1) M5-1000X1 1,000 Watt Amp + Jeep Specific Tune
(1) PLC2 Bass Level Control + Custom Knob
(1) Complete Wiring Kit + Fuse block
(1) Factory Jack Relocation Kit
(1) 12V Relocation Kit
(1) Rockford Fosgate Duck
Installation:
• (6~8) Hours Typical
Special Shipping & Delivery:
• Please allow 3–10 business days
• Residential driveway delivery
• Freight truck required
• Signature required
• No UPS/FedEx delivery
• Driver will call regarding delivery
Technologies
Rockford Factory Fit & Finish
Designed and engineered to compliment the factory fit and finish of your vehicle. These components are
Plug-And-Play Design
The system is designed for plug-and-play operation utilizing pre-terminated wiring harnesses and quick connect
Performance Sound | Jeep
With a total of 1800 watts, this all-in-one audio kit is equipped with two subwoofers, front and overhead coaxial
Element Ready™ | Jeep
Purpose Built for the off-road environment, Rockford’s Element Ready™ products are built to stand up to Water,
Specs
Specifications
10
| Total Power | 1,800 Watts |
| Amplifiers | (1) M5-800X4 (1) M5-1000X1 |
| Fuse Size | 150 ANL |
| Accessory Pack | (1) ABS Drill Template for Jeep (3) Flat Washer M4-0.7, 9mm OD, 1mm TH (20) Nylon Cable Tie 0.17 x 8 in. (3) Stamped Clip (1) 12V Socket Removal Tool for Jeep Wrangler (1) Hole Saw with Arbor, 20mm Diameter (3) Large Screw, M4x0.7, x 8mm (3) Thread Forming Screw, 1/4-14 THD, 0.75 in L, Hex, 0.375 (1) Drill Bit, 4.76mm Diameter, 89mm L (2) Flat Flange Washer 2.5mm (1) Subwoofer Bracket Passenger (1) Subwoofer Bracket Driver (1) Machine Screw, M5, 16mm, Hex (1) SHCS Screw, M5x0.8, 30mm L, Hex, 4mm (2) Coupling Nut, M6x1, 10mm Diam., 20mm L (2) SHCS Screw, M6x1, 45mm L, Hex, 5mm (4) FHCS Screw, M6x1, 10mm L, Hex, 4mm (1) Nylon Nut, M5x0.8, 8mm Hex, 5mm Tall (1) Steel-Neoprene Sealing Washer (2) Clipped Washer, 5.3 ID, 16.0 OD |
| Front Speakers | (2) M2-TS (2) TMS65 |
| Soundbar Speakers | (2) TMS65 |
| Subwoofers | (2) T1S2-10 |
| Shipping Dimensions | 23.1” x 28.1” x 55.9” 58.7 cm x 71.5 cm x 14.20 cm |
| Shipping Weight | 98.1 Lbs (44.5 kg) |
| Digital Signal Processor | (1) DSR1J (Maestro Jeep Programed) |
Reviews (0)
—
No average rating yet
0 reviews
No written reviews are live yet. Signed-in customers can submit one below.
No written reviews are live for this item yet.
Support
Return Authorization
If you bought this product from Onkar Electronics, use the Contact Us page on the Onkar Electronics website and we will help with return authorization and warranty support. If you purchased it from another dealer, contact that authorized dealer first for return assistance.
Popular Questions
Are Jeep components sold separately?
by Steve
· 1 month ago
· Updated
I'm looking at the Jeep Wrangler and Gladiator complete audio kits and I really like the speaker pods, subwoofer enclosures, and amp rack. Are any of these items available for purchase separately?
No, the components included in the complete Jeep kits are not available for purchase separately. They are precisely matched to work and complement the other components in the kit.
Complete Kit Advantages:
- Components perfectly matched to each other
- Plug-n-Play connectivity with included wiring harness
- DSP Presets pre-tuned for optimal sound
- Amplifier power output is optimized for speaker power handling
Compatibility
YESModel IS compatible with kit |
NOModel NOT compatible with kit |
NOT AVAILABLEModel not produced this year |
|---|
COMPATIBLEManual TransmissionM |
COMPATIBLETow PackageD |
COMPATIBLEPremium AudioP |
COMPATIBLEDiesel V6D |
NO12" Screen |
|---|
| SPORT MODELS | 2020 | 2021 | 2022 | 2023 | 2024 |
|---|---|---|---|---|---|
| Gladiator Sport | ✓ | ✓D | ✓D | ✓ | X |
| Gladiator Sport S | ✓ | ✓D | ✓D | ✓D | X |
| WILLYS MODELS | 2020 | 2021 | 2022 | 2023 | 2024 |
|---|---|---|---|---|---|
| Gladiator Willys | — | ✓D | ✓D | ✓D | X |
| Gladiator Willys Sport | — | ✓D | ✓D | ✓D | — |
| RUBICON MODELS | 2020 | 2021 | 2022 | 2023 | 2024 |
|---|---|---|---|---|---|
| Gladiator Rubicon | ✓ | ✓D | ✓D,P | ✓D,P | X |
| LIMITED MODELS | 2020 | 2021 | 2022 | 2023 | 2024 |
|---|---|---|---|---|---|
| Gladiator 80th Anniversary | — | ✓D,P | — | — | — |
| Gladiator Altitude | ✓ | — | ✓D | — | — |
| Gladiator California Edition | — | ✓D | — | — | — |
| Gladiator FarOut | — | — | — | ✓D,P | — |
| Gladiator Freedom | — | ✓D | — | ✓ | X |
| Gladiator High Altitude | — | ✓D,P | ✓D,P | ✓D,P | X |
| Gladiator Overland | ✓ | ✓D | ✓D,P | ✓D,P | — |
| Gladiator North Edition | ✓P | — | — | — | — |
| Gladiator Mojave | ✓ | ✓ | ✓P | ✓P | X |
| Gladiator Texas Trail | — | ✓D | ✓D | ✓ | X |
A Automatic Transmission: requires no special modifications.
M Manual Transmission: requires removal of supplied grommet & drilling 3/4-inch hole through firewall to route power wire.
D Diesel V6: requires removal of fuse-holder from bracket to mount separately on firewall.
D Diesel + Tow Package: requires purchase of PLC2 remote bass control and alternate mounting location.
P Premium Audio: available on this model is replaced by Rockford Fosgate audio kit.
V8 6.4L V8: requires removal of fuse-holder from bracket to mount separately on firewall.
