Rockford Fosgate 24WRNGLER-STG31,800 Watt All-In-One Audio Kit for Select 2024+ Jeep Wrangler JL
All-in-one 1,800 watt Stage‑3 audio system engineered for select 2024+ Jeep Wrangler JL. The kit combines pre-tuned amplifiers, a DSP with a Jeep-specific tune, and Rockford Factory fit-and-finish in a plug-and-play package designed to complement the factory interior.
Highlights
- High output performance
- 2-Year Warranty
- Nearly 2x louder than premium audio system
- Plug-and-Play design for easy installation
Key specs
Full specs- Total Power
- 1,800 Watts
- Front Speakers
- (2) M2-TS (2) TMS65
- Digital Signal Processor
- (1) DSR1J (Maestro Jeep Programmed)
- Subwoofers
- (1) T1S2-12
- Amplifiers
- (1) M5-800X4 (1) M5-1000X1
- Fuse Size
- 150 ANL
- Accessory Pack
- 1130-76551-01: (1) ABS Drill Template for Jeep (3) Flat Washer M4-0.7, 9mm OD, 1mm TH (20) Nylon Cable Tie 0.17 x 8 in. (3) Stamped Clip (1) 12V Socket Removal Tool for Jeep Wrangler (1) Hole Saw with Arbor, 20mm Diameter (3) Large Screw, M4x0.7, x 8mm (3) Thread Form Screw, 1/4-14, 0.75 in L, Hex, 0.375 (1) Machine Screw, M6x1.0, 12mm, Hex (DSP on 24+) (1) Drill Bit, 4.76mm Diameter, 89mm L (1) Drill Bit, 13 mm (sub bracket) 1130-79148-01 (Sub): (2) Short Spacer (2) Long Spacer (1) Subwoofer Ext. Harness 2 Conductor (2) Machine Screw M6x1.0, 40mm L, HEX, Black (4) Machine Screw M6x1.0, 18mm L, HEX, Black
- Shipping Weight
- 69 Lbs. (31.3 kg)
Key specs
Full specs- Total Power
- 1,800 Watts
- Front Speakers
- (2) M2-TS (2) TMS65
- Digital Signal Processor
- (1) DSR1J (Maestro Jeep Programmed)
- Subwoofers
- (1) T1S2-12
Highlights
Overview- High output performance
- 2-Year Warranty
- Nearly 2x louder than premium audio system
Overview
All-in-one 1,800 watt Stage‑3 audio system engineered for select 2024+ Jeep Wrangler JL. The kit combines pre-tuned amplifiers, a DSP with a Jeep-specific tune, and Rockford Factory fit-and-finish in a plug-and-play package designed to complement the factory interior.
Best for
- Owners of select 2024+ Jeep Wrangler JL seeking a high-output, vehicle-specific sound upgrade
- Users who want a plug-and-play system with pre-tuned amplifiers and DSP
- Off-road drivers who prefer components built to Rockford’s Element Ready™ standards
Key points
- Total system power: 1,800 watts
- Includes vehicle-specific DSP with a custom Jeep tune
- Two amplifiers: M5-1000X1 (1,000W) and M5-800X4 (800W), pre-tuned
- Speaker and subwoofer components: (2) M2 1” dash tweeters + bezels, (2) TMS65 6.5" front speakers + enclosures, (1) T1S2-12 12" subwoofer + enclosure
- Controls and installation parts: PLC2 bass level control with custom knob, complete wiring kit, fuse block, 12V relocation kit
- Plug-and-play design with Rockford Factory fit-and-finish and Element Ready™ construction
Fit and use
Designed to integrate with the factory interior and retain the existing overhead soundbar on compatible vehicles. The system is plug-and-play and ships with the wiring kit and installation hardware; typical installation is listed as 6–8 hours (actual time varies). The DSP and amps arrive with Jeep-specific tuning for a ready-to-use high-output setup.
What to know
Confirm compatibility with your specific vehicle (select 2024+ Jeep Wrangler JL) before purchase. Amplifiers and DSP are pre-tuned for Jeep; review the programming & tuning guide if adjustments are needed. Element Ready™ construction indicates components are built for rugged, off-road environments — review product res…
Highlights
Key features
- High output performance
- 2-Year Warranty
- Nearly 2x louder than premium audio system
- Plug-and-Play design for easy installation
- Direct bolt into vehicle using OEM mounting holes
- T-harness integration eliminates cutting or splicing wires
- Integrated OEM style enclosures w/ factory connectors
- Minimal cutting (for models that require 12v accessory relocation only)
- Audio integration into OEM CAN-bus system
- DSP recognition with auto-loading Jeep Wrangler specific tune
- Custom bass level control matches OEM dash and controls
- Element Ready™ enclosures designed to withstand heat, water, and UV rays
More info
Manufacturer details
The Stage-3 Jeep audio kits were developed to take your 4×4 adventure to the next level. This 1800 watt plug and play audio kit delivers high output performance; a Jeep specific tune to ensure an epic listening experience as well as a straightforward installation. The system is designed and engineered to match and compliment your factory interior and was built Element Ready™ ensuring lasting performance no matter the terrain.
Performance Sound: With a total of 1800 watts, this audio kit is equipped with one 12" subwoofer, front 6.5" coaxial speakers, front 1”inch tweeters, and both a 1000-watt and an 800-watt amplifier that are pre-tuned. The kit also features a Digital Signal Processor with a specific Jeep tune, all to ensure the best-in-class listening experience
Element Ready™: Purpose built for the off-road environment, Rockford’s Element Ready™ products are built to stand up to water, dirt, mud and UV rays, making sure all your audio components perform regardless of the conditions.
Bass Control: Equipped with a pre-installed bass level controller, you now have precise control over the amount of bass output, allowing you to tailor your audio experience to your exact preferences.
RF3 (Rockford Factory Fit and Finish): Designed and engineered to match and compliment the factory fit and finish of your vehicle. These components are purpose built to the exact specifications to ensure the best-in-class fitment and look.
Compatibility Chart: Please review "compatibility" tab for fitment before purchasing.
Product Launch
Product Overview
Installation Tutorial
Programming & Tuning Guide
Additional details
WHERE SOUND MEETS ADVENTURE
The Jeep Wrangler Stage 3 is an all-in-one 1,800 Watt high-performance audio system that’s 4x louder than the base audio and nearly 2x louder than the premium audio system. It stands apart from the competition with its fully integrated Digital Signal Processor tuned specifically for Jeep Wrangler by Rockford Fosgate engineers using a custom designed 6-microphone array. This system retains the existing overhead soundbar.
Components
(2) M2-TS M2 1” Dash Tweeters + Bezels
(2) TMS65 6.5” Front Speakers + Enclosures
(1) T1S2-12 12” Subwoofer + Enclosure
(1) DSP + Jeep Specific Tune
(1) M5-800X4 800 Watt Amp + Jeep Specific Tune
(1) M5-1000X1 1,000 Watt Amp + Jeep Specific Tune
(1) PLC2 Bass Level Control + Custom Knob
(1) Complete Wiring Kit + Fuse block
(1) 12V Relocation Kit
(1) Rockford Fosgate Duck
Installation:
• (6~8) Hours Typical
Special Shipping & Delivery:
• Please allow 3–10 business days
• Residential driveway delivery
• Freight truck required
• Signature required
• No UPS/FedEx delivery
• Driver will call regarding delivery
Technologies
Rockford Factory Fit & Finish
Designed and engineered to compliment the factory fit and finish of your vehicle. These components are
Element Ready™ | Jeep
Purpose Built for the off-road environment, Rockford’s Element Ready™ products are built to stand up to Water,
Plug-And-Play Design
The system is designed for plug-and-play operation utilizing pre-terminated wiring harnesses and quick connect
Performance Sound | Jeep
With a total of 1800 watts, this all-in-one audio kit is equipped with two subwoofers, front and overhead coaxial
Specs
Specifications
8
| Total Power | 1,800 Watts |
| Front Speakers | (2) M2-TS (2) TMS65 |
| Digital Signal Processor | (1) DSR1J (Maestro Jeep Programmed) |
| Subwoofers | (1) T1S2-12 |
| Amplifiers | (1) M5-800X4 (1) M5-1000X1 |
| Fuse Size | 150 ANL |
| Accessory Pack | 1130-76551-01: (1) ABS Drill Template for Jeep (3) Flat Washer M4-0.7, 9mm OD, 1mm TH (20) Nylon Cable Tie 0.17 x 8 in. (3) Stamped Clip (1) 12V Socket Removal Tool for Jeep Wrangler (1) Hole Saw with Arbor, 20mm Diameter (3) Large Screw, M4x0.7, x 8mm (3) Thread Form Screw, 1/4-14, 0.75 in L, Hex, 0.375 (1) Machine Screw, M6x1.0, 12mm, Hex (DSP on 24+) (1) Drill Bit, 4.76mm Diameter, 89mm L (1) Drill Bit, 13 mm (sub bracket) 1130-79148-01 (Sub): (2) Short Spacer (2) Long Spacer (1) Subwoofer Ext. Harness 2 Conductor (2) Machine Screw M6x1.0, 40mm L, HEX, Black (4) Machine Screw M6x1.0, 18mm L, HEX, Black |
| Shipping Weight | 69 Lbs. (31.3 kg) |
Reviews (0)
—
No average rating yet
0 reviews
No written reviews are live yet. Signed-in customers can submit one below.
No written reviews are live for this item yet.
Support
Return Authorization
If you bought this product from Onkar Electronics, use the Contact Us page on the Onkar Electronics website and we will help with return authorization and warranty support. If you purchased it from another dealer, contact that authorized dealer first for return assistance.
Popular Questions
Are Jeep components sold separately?
by Steve
· 1 month ago
· Updated
I'm looking at the Jeep Wrangler and Gladiator complete audio kits and I really like the speaker pods, subwoofer enclosures, and amp rack. Are any of these items available for purchase separately?
No, the components included in the complete Jeep kits are not available for purchase separately. They are precisely matched to work and complement the other components in the kit.
Complete Kit Advantages:
- Components perfectly matched to each other
- Plug-n-Play connectivity with included wiring harness
- DSP Presets pre-tuned for optimal sound
- Amplifier power output is optimized for speaker power handling
Compatibility
YESVehicle IS compatible with kit |
NOVehicle NOT compatible with kit |
NOT AVAILABLEVehicle not produced this year |
|---|
YES2-Door (JL) |
YES4-Door (JL) |
YESHybrid Models |
YES12.3" Center Display |
|---|
COMPATIBLEPowered Seats |
COMPATIBLEManual TransmissionM |
COMPATIBLETow PackageD |
COMPATIBLEPremium AudioP |
COMPATIBLEDiesel V6D |
|---|
| Jeep Type | Model Number | Description | Photo | Buy Now |
|---|---|---|---|---|
| 4-Door | Mopar 7ET48TX7AB | Quarter Inner Lower Panel | BUY NOW | |
| 4-Door | Mopar 7EU72TX7AB | JL Quarter Cargo Trim Right Hand Side | BUY NOW | |
| 4-Door | Mopar 7EW94TX7AC | Wheelhouse Carpet | BUY NOW | |
| 4-Door | Mopar 5PL10XXXAA | Carpet Clip | BUY NOW | |
| 4-Door | Mopar 5PL11TX7AA | Carpet Clip | BUY NOW | |
| 4-Door | Mopar 6MJ08TX7AB | Carpet Clip | BUY NOW | |
| 4-DOOR 4XE | Mopar 6SZ33TX7AB | Cargo Area Cover | BUY NOW |
| SPORT MODELS | 2018 | 2019 | 2020 | 2021 | 2022 | 2023 | 2024 | 2025 |
|---|---|---|---|---|---|---|---|---|
| Wrangler Sport | X | X | X | X | X | X | ✅ | ✅ |
| Wrangler Sport S | X | X | X | X | X | X | ✅ | ✅ |
| WILLYS MODELS | 2018 | 2019 | 2020 | 2021 | 2022 | 2023 | 2024 | 2025 |
|---|---|---|---|---|---|---|---|---|
| Wrangler Willys | — | — | X | X | X | X | ✅ | ✅ |
| Wrangler Willys AEV Upcountry Package | — | — | — | — | — | — | ✅ | — |
| Wrangler Willys AEV Upcountry + Package | — | — | — | — | — | — | ✅ | — |
| Wrangler Willys Sport | — | — | X | X | X | X | — | — |
| Wrangler Willys Wheeler | X | — | — | — | — | — | — | — |
| Wrangler Willys Wheeler W | X | — | — | — | — | — | — | — |
| SAHARA MODELS | 2018 | 2019 | 2020 | 2021 | 2022 | 2023 | 2024 | 2025 |
|---|---|---|---|---|---|---|---|---|
| Wrangler Sahara | X | — | — | — | — | — | — | — |
| RUBICON MODELS | 2018 | 2019 | 2020 | 2021 | 2022 | 2023 | 2024 | 2025 |
|---|---|---|---|---|---|---|---|---|
| Wrangler Rubicon | X | X | X | X | X | X | ✅ | ✅ |
| Wrangler Rubicon AEV Upcountry Package | — | — | — | — | — | — | ✅ | — |
| Wrangler Rubicon AEV Upcountry + Package | — | — | — | — | — | — | ✅ | — |
| Wrangler Rubicon AEV Level II Package | — | — | — | — | — | — | ✅ | — |
| Wrangler Rubicon Recon | X | — | X | — | — | — | — | — |
| Wrangler Rubicon X | — | — | — | — | — | X | ✅ | ✅ |
| LIMITED EDITION MODELS | 2018 | 2019 | 2020 | 2021 | 2022 | 2023 | 2024 | 2025 |
|---|---|---|---|---|---|---|---|---|
| Wrangler 80th Anniversary | — | — | — | X | — | — | — | — |
| Wrangler Altitude | X | — | — | — | — | — | — | — |
| Wrangler Black and Tan | — | — | X | — | — | — | — | — |
| Wrangler Freedom | X | X | X | X | — | X | — | — |
| Wrangler Golden Eagle | X | — | — | — | — | — | — | — |
| Wrangler Islander | — | — | — | X | — | — | — | — |
| Wrangler North Edition | — | — | X | — | — | — | — | — |
| SPORT MODELS | 2018 | 2019 | 2020 | 2021 | 2022 | 2023 | 2024 | 2025 |
|---|---|---|---|---|---|---|---|---|
| Wrangler Unlimited SportM | X | X | X | X | — | X | ✅ | ✅ |
| Wrangler Unlimited Sport SM | X | X | XD | XD | XD | XD | ✅ | ✅ |
| Wrangler Unlimited Sport AltitudeM | — | X | XD | X | X | X | — | — |
| WILLYS MODELS | 2018 | 2019 | 2020 | 2021 | 2022 | 2023 | 2024 | 2025 |
|---|---|---|---|---|---|---|---|---|
| Wrangler Unlimited WillysM | — | — | XD | XD | X | X | ✅ | ✅ |
| Wrangler Unlimited Willys AEV Upcountry Package | — | — | — | — | — | — | ✅ | — |
| Wrangler Unlimited Willys AEV Upcountry + Package | — | — | — | — | — | — | ✅ | — |
| Wrangler Unlimited Willys SportM | — | — | X | X | XD | X | — | — |
| Wrangler Unlimited Willys WheelerM | X | — | — | — | — | — | — | — |
| Wrangler Unlimited Willys Wheeler WM | X | — | — | — | — | — | — | — |
| SAHARA MODELS | 2018 | 2019 | 2020 | 2021 | 2022 | 2023 | 2024 | 2025 |
|---|---|---|---|---|---|---|---|---|
| Wrangler Unlimited SaharaM | X | X | X | X | XD,P | XA,D,P | ✅ | ✅ |
| Wrangler Unlimited Sahara AltitudeM | — | X | XD | XD | XP | XA,P | — | — |
| Wrangler Unlimited Sahara High AltitudeD | — | — | XP | XP | — | — | — | — |
| RUBICON MODELS | 2018 | 2019 | 2020 | 2021 | 2022 | 2023 | 2024 | 2025 |
|---|---|---|---|---|---|---|---|---|
| Wrangler Unlimited RubiconM | X | X | XD | XD | XD,P | XD,P | ✅ | ✅ |
| Wrangler Unlimited Rubicon AEV Upcountry Package | — | — | — | — | — | — | ✅ | — |
| Wrangler Unlimited Rubicon AEV Upcountry + Package | — | — | — | — | — | — | ✅ | — |
| Wrangler Unlimited Rubicon 392V8 | — | — | — | XV8,P | XV8,P | XV8,P | ✅ | — |
| Wrangler Unlimited Rubicon 392 20th AnniversaryV8 | — | — | — | — | — | XP | — | — |
| Wrangler Unlimited Rubicon 392 AEV Level II PackageV8 | — | — | — | — | — | — | ✅ | — |
| Wrangler Unlimited Rubicon FaroutD | — | — | — | — | — | XP | — | — |
| Wrangler Unlimited Rubicon Recon | XM | — | XA | — | — | — | — | — |
| Wrangler Unlimited Rubicon X | — | — | — | — | — | X | ✅ | ✅ |
| LIMITED EDITION MODELS | 2018 | 2019 | 2020 | 2021 | 2022 | 2023 | 2024 | 2025 |
|---|---|---|---|---|---|---|---|---|
| Wrangler Unlimited 80th Anniversary | — | — | — | XP | — | — | — | — |
| Wrangler Unlimited AltitudeM | X | — | — | — | — | — | — | — |
| Wrangler Unlimited Black and TanM | — | — | X | — | — | — | — | — |
| Wrangler Unlimited FreedomM | X | X | X | X | — | X | — | — |
| Wrangler Unlimited Golden EagleM | X | — | — | — | — | — | — | — |
| Wrangler Unlimited High Tide | — | — | — | — | X | X | — | — |
| Wrangler Unlimited High Altitude | — | — | — | — | XP | XP | — | — |
| Wrangler Unlimited IslanderM | — | — | — | X | — | — | — | — |
| Wrangler Unlimited Moab | XP | XP | — | — | — | — | — | — |
| Wrangler Unlimited North Edition | — | — | XP | — | — | — | — | — |
| MODEL | 2018 | 2019 | 2020 | 2021 | 2022 | 2023 | 2024 | 2025 |
|---|---|---|---|---|---|---|---|---|
| Wrangler Sport S 4xe | — | — | — | — | — | XP | ✅ | — |
| Wrangler Willys 4xe | — | — | — | — | — | X | ✅ | ✅ |
| Wrangler Willys 41 4xe | — | — | — | — | — | — | — | ✅ |
| Wrangler Sahara 4xe | — | — | — | XP | XP | XP | ✅ | ✅ |
| Wrangler Rubicon 20th Anniversary 4xe | — | — | — | — | — | XP | — | — |
| Wrangler Rubicon 4xe | — | — | — | XP | XP | XP | ✅ | ✅ |
| Wrangler Rubicon X 4xe | — | — | — | — | — | X | ✅ | — |
| Wrangler High Altitude 4xe | — | — | — | XP | XP | XP | ✅ | ✅ |
A Automatic Transmission: requires no special modifications.
M Manual Transmission: requires removal of supplied grommet & drilling 3/4-inch hole through firewall to route power wire.
D Diesel V6: requires removal of fuse-holder from bracket to mount separately on firewall.
D Diesel + Tow Package: requires purchase of PLC2 remote bass control and alternate mounting location.
P Premium Audio: requires WRNGLR-TRIM to replace OEM panels.
V8 6.4L V8: requires removal of fuse-holder from bracket to mount separately on firewall.
Videos
Product Launch
This product overview highlights the 2024 Jeep Wrangler Stage-3 audio kit and its components.
Similar products
Compare nearby options
Rockford Fosgate
18WRNGLER-STG5 1,800 Watt All-In-One Audio Kit for Select 2018-2023 Jeep Wrangler Unlimited JL
$8479.99CAD
$9979.99
In stock
Rockford Fosgate
20GLADR-STG5 1,800 Watt All-In-One Audio Kit for Select 2020-2023 Jeep Gladiator JT
$8479.99CAD
$9979.99
In stock
Rockford Fosgate
WRNGLR-TRIM Trim Kit for Jeep Wrangler Unlimited JL with OEM Premium Audio
$709.99CAD
$839.99
In stock
