Cerwin Vega

Cerwin Vega CSP66CSP66 2- Way 6x6" Passive Column Speaker

CSP66 2- Way 6x6" Passive Column Speaker Looking for massive, high-impact sound that still blends right into your space? Meet the CSP66—our flagship professional column speaker, highly regarded for its high sensitivity and bright, clear sonic performance.

Key specs

Full specs
Type
Passive
Frequency Response (-3dB)
80Hz − 18kHz
Sensitivity (1W/1M)
100 dB
MAX.SPL
127 dB Continuous, 133dB Peak
Dispersion (Horizontal)
110°× 25°
Drivers
6×6′′ (150mm)LF, 2×1′′ (25mm)HF
Rated Power
480W RMS/ 1920W Peak
Nominal Impedance
6 ohms

Key specs

Full specs
Type
Passive
Frequency Response (-3dB)
80Hz − 18kHz
Sensitivity (1W/1M)
100 dB
MAX.SPL
127 dB Continuous, 133dB Peak
Overview

CSP66 2- Way 6x6" Passive Column Speaker

Looking for massive, high-impact sound that still blends right into your space? Meet the CSP66—our flagship professional column speaker, highly regarded for its high sensitivity and bright, clear sonic performance. Gone are the days of oversized, obtrusive speakers. Our column series is built for spaces like yours: premium conference centers, lecture halls, houses of worship, and multi-purpose venues where clean sound and a clean look are the top priority. The CSP66 delivers high-fidelity audio with an ultra-wide 110° horizontal coverage, ensuring an even distribution of sound so that every person in the room gets the same pristine experience—no hot spots, no dead zones. What makes it special? It’s the ultimate expression of our array technology. The CSP66 is equipped with six 6" neodymium mid-woofers and two 1" exit-throat (44mm) neodymium high-frequency drivers. Combined with a precision line-array horn, this configuration ensures high-fidelity sound and stays authoritative at a staggering 133dB peak. With an exceptional 100dB sensitivity, it provides the "reach" and clarity required for the most demanding professional environments. But here’s the best part: the CSP66 is designed for total flexibility. While it delivers incredible full-range performance on its own, it is built to scale. For maximum impact, simply pair it with the SUBA18-CSP66 subwoofer to form a complete, formidable sound system that meets the audio needs of any small to medium-sized venue. Despite its power and 50-inch (1290mm) height, it features a multi-layer composite plywood cabinet with an abrasion-resistant polyurea finish, ensuring excellent durability while maintaining a slim, sophisticated profile. Great sound shouldn’t be complicated, even at the highest level. With the CSP66, you get professional-grade audio in a discreet, flexible, and truly easy-to-use format. No hype, just performance that fits your grandest vision.
Specs

Specifications

11
TypePassive
Frequency Response (-3dB)80Hz − 18kHz
Sensitivity (1W/1M)100 dB
MAX.SPL127 dB Continuous, 133dB Peak
Dispersion (Horizontal)110°× 25°
Drivers6×6′′ (150mm)LF, 2×1′′ (25mm)HF
Rated Power480W RMS/ 1920W Peak
Nominal Impedance6 ohms
Crossover Frequency1.8kHz
Input Connectors2×Speakon NL4
Dimensions50.79"×9.53"×6.22"(1290×242×158mm)
