Rockford Fosgate RZR24XP-STG1Stage 1 Aftermarket 100-Watt Audio System for 2024+ RZR XP

The Stage 1 system is a purpose-built, 100‑watt front audio upgrade for 2024+ Polaris RZR XP. It pairs a PMX‑1 IPX6 Bluetooth source unit (with built‑in amplifier) to two Element Ready 6.5" coax speakers in custom enclosures for a plug‑and‑play installation.

Highlights

Includes wired antenna
Element Ready™ to withstand the harsh outdoor environment like dust, water, and UV rays
True plug-and-play design with OEM connectors for easy installation
Direct bolt into vehicle using OEM mounting holes. Minimal drilling required

Key specs

Speaker Qty: 2
Amplifier Type: Internal
Expansion Ports: None
Total Power: 100 Watts
Mounting Hardware: Yes
Grille-Trim Ring Included: Yes
Included In The Box: (1) PMX Wiring Harness PMX-DK • (4) Torx plastic tapping screw, ¼” x 1” long • (1) PMX radio bracket RZR24XP-FSE • (1) Driver FSE • (1) Passenger FSE • (6) Torx Bolt M6 x 0.75mm, 14mm long • (12) Hex Bolt M4 x 0.7mm, 22mm long • (2) Hex Screw M6 self-tapping • (2) Tube clamp mount bracket
Shipping Weight: 25 Lbs. (11.3 Kg)

Key specs

Speaker Qty: 2
Amplifier Type: Internal
Expansion Ports: None
Total Power: 100 Watts

Highlights

Includes wired antenna
Element Ready™ to withstand the harsh outdoor environment like dust, water, and UV rays
True plug-and-play design with OEM connectors for easy installation

Overview

Best for

Owners of 2024+ Polaris RZR XP seeking a factory-integrated audio upgrade
Riders who want a weather-resistant source unit and speakers for open-cab off‑road use
Users who plan to expand to rear speakers later

Key points

Total system power: 100 watts (2‑speaker, front)
Source unit: PMX‑1 Bluetooth controller with built‑in amplifier; IPX6 water-intrusion rating
Speakers: two 6.5" Element Ready™ coaxial front speakers
Enclosures are custom fabricated to fit the RZR XP interior without loss of functional cabin space
Complete wiring harness with OEM-style connectors for plug‑and‑play integration
Allows future expansion to two additional rear speakers

Fit and use

Designed specifically for 2024+ Polaris RZR XP. The system uses OEM-style connectors and a plug-and-play harness to minimize vehicle modification (advertised as minimal drilling, no cutting). The PMX‑1 serves as the primary audio controller and supports Bluetooth and USB playback. The custom enclosures are intended to integrate into the cabin without reducing functional space.

What to know

IPX6 rating indicates protection against strong water jets but does not imply submersion suitability—follow manufacturer guidance for outdoor use. The system is a 2‑speaker front kit; rear speakers can be added later using the provided expansion provisions. Typical installation time is listed at about 3 hours; exact t…

Highlights

Key features

Includes wired antenna
Element Ready™ to withstand the harsh outdoor environment like dust, water, and UV rays
True plug-and-play design with OEM connectors for easy installation
Direct bolt into vehicle using OEM mounting holes. Minimal drilling required
PMX-1: Punch Marine Grade Media Receiver with 2.3" Dot Matrix Display
2-Year Warranty
RZR24XP-DK: source unit dash kit for select 2024+ RZR® models
RZR24XP-FSE: 6.5" front speaker enclosures for select 2024+ RZR® models
Enclosures for speakers/subwoofer integrate with no loss of passenger space
Video installation tutorial with easy-to-follow instructions
M0-65B: M0 6.5" Element Ready™ Speakers - Black
Dust Resistant

More info

Manufacturer details

The all-new Rockford Fosgate aftermarket Stage 1 is a premium 100-Watt 2-speaker audio system for 2024+ Polaris RZR XP and features our PMX-1 Bluetooth® source unit as your audio controller. The PMX-1 is an IPX6 rated and features a built-in amplifier that powers Element Ready™ front 6.5” coax speakers. All enclosures are custom fabricated and designed to fit seamlessly into the interior without loss of functional cabin space. The system features a complete wiring harness with OEM style connectors for true plug-and-play integration and allows for future expansion of two additional rear speakers.

Dynamic Performance: Featuring a plug-and-play design, this system is equipped with two 6.5-inch speakers and a 2.3-inch source unit, delivering the perfect balance of powerful performance and effortless installation.

Plug-and-Play Design: Minimal drilling, no cutting and designed to work right out of the box. Simple installation ensures less time in the garage and more time out riding..

Bluetooth Control: With Bluetooth connectivity it’s easy to control your music and take your playlist with you no matter where you go.

Element Ready™: Purpose Built for the outdoor environment, Rockford’s Element Ready™ products are built to stand up to Water, Salt, and UV, making sure your products stand the test of time.

Compatibility: Refer to our compatibility chart to verify fitment before purchasing.

2024+ RZR XP | Product Launch
2024+ RZR XP | Product Overview

Download RF CONNECT to control the PMX-1:

Additional details

DYNAMIC PERFORMANCE

The RZR24XP-STG1 is a performance, 2-speaker, 100-watt front audio system.

Components:
• (1) Bluetooth® Source Unit
• (2) 6.5” M0 Element Ready™ Speakers

Installation:
• (3) Hours Typical

Upgrade This Kit:
• (1) PMX-ANT Powered Antenna
• (1) PMX-USBP USB Extension Port
• (1) PMX-BTUR Steering Wheel Remote

• (2) M0WL-65MB 6.5" M0 Rear Moto-Cans

• (1) PMX-3 SiriusXM Ready® Source Unit
• (1) MX-CAM-RZR14 Backup Cam (for PMX-3)

Technologies

Dust Resistant

Displays and motor structures are sealed tight so they look and sound as clear as possible no matter how many

IPX6 Water Intrusion Rating

A device with a level 6 water resistance rating can survive strong water jets projected by a 12.5mm nozzle at any

MP3 Playback

This source unit supports MP3 file format playback.

USB Playback

This source unit supports playback from a USB device.

Stainless Hardware

Stainless hardware is used to its natural resistance to corrosion and rusting. This ensures electrical connections

Corrosion Protection

Components are tested for salt spray corrosion resistance.

Thermal Shock Resistant

Components are designed to withstand extreme temperature fluctuations ensuring they perform day-in and day-out.

UV Inhibitor Materials

Centrex and ASA plastic materials are used for their UV radiation resistance and components are tested in

Vibration Resistant

Components are able to withstand shock and vibration conditions common with outdoor vehicles.

Showing the main technologies for this product.

Specs

Specifications

Speaker Qty	2
Amplifier Type	Internal
Expansion Ports	None
Total Power	100 Watts
Mounting Hardware	Yes
Grille-Trim Ring Included	Yes
Included In The Box	(1) PMX Wiring Harness PMX-DK • (4) Torx plastic tapping screw, ¼” x 1” long • (1) PMX radio bracket RZR24XP-FSE • (1) Driver FSE • (1) Passenger FSE • (6) Torx Bolt M6 x 0.75mm, 14mm long • (12) Hex Bolt M4 x 0.7mm, 22mm long • (2) Hex Screw M6 self-tapping • (2) Tube clamp mount bracket
Shipping Weight	25 Lbs. (11.3 Kg)
Included Components	(1 ea) PMX-1 (1 pr) M0-65B

What's in the box

Qty	Part number	Item details
1	—	PMX Wiring Harness PMX-DK
4	—	Torx plastic tapping screw, ¼” x 1” long
1	—	PMX radio bracket RZR24XP-FSE
1	—	Driver FSE
1	—	Passenger FSE
6	—	Torx Bolt M6 x 0.75mm, 14mm long
12	—	Hex Bolt M4 x 0.7mm, 22mm long
2	—	Hex Screw M6 self-tapping
2	—	Tube clamp mount bracket
