P1V2-4Punch P1 4” 3-Way Coaxial Speaker
Variants
The Punch P1 4” 3-way coaxial speaker is an all-in-one, vehicle-compatible upgrade engineered to fit modern factory locations. It combines a redesigned frame and adapters with a 3-way coaxial layout for improved clarity and output.
Highlights
- Updated mounting flanges for direct fitment in new vehicles
- 3/4” (19 mm) Tetolon® inverted dome tweeter for reliable performance under stress
- 3/8” (9 mm) Polypropylene piezo super tweeter for enhanced high-frequency response
- 20-40% Mica reinforced Polypropylene curvilinear cone for enhanced rigidity and sonic quality
Key specs
Full specs- Speaker Type
- Coaxial
- Midrange Size (Nominal Diameter)
- 4"
- Tweeter Size (Nominal Diameter)
- 3/4” (19 mm) Inverted Dome
- Piezo Size (Nominal Diameter)
- 3/8” (9 mm) Co-Witnessed Convex
- Nominal Impedance (Ohms)
- 4Ω
- Frequency Response (Hz)
- 75Hz - 25kHz
- Voice Coil Diameter (in/mm)
- 1" (25.4 mm)
- Crossover
- Tweeter High-Pass: 9kHz @ 6 dB/Octave Midrange Bass Blocker: 1,200Hz @ 6 dB/Octave (33µF)
Key specs
Full specs- Speaker Type
- Coaxial
- Midrange Size (Nominal Diameter)
- 4"
- Tweeter Size (Nominal Diameter)
- 3/4” (19 mm) Inverted Dome
- Piezo Size (Nominal Diameter)
- 3/8” (9 mm) Co-Witnessed Convex
Highlights
Overview- Updated mounting flanges for direct fitment in new vehicles
- 3/4” (19 mm) Tetolon® inverted dome tweeter for reliable performance under stress
- 3/8” (9 mm) Polypropylene piezo super tweeter for enhanced high-frequency response
Overview
The Punch P1 4” 3-way coaxial speaker is an all-in-one, vehicle-compatible upgrade engineered to fit modern factory locations. It combines a redesigned frame and adapters with a 3-way coaxial layout for improved clarity and output.
Best for
- Basic OEM systems with single-speaker locations
- Door or rear deck replacements where space is limited
- Upgrading factory single-cone drivers to a coaxial with a tweeter
Key points
- Auto Fit Architecture: re-designed frame, mounting holes, removable motor cover, and speaker diameter for easier integration
- 3-way coaxial design with precision-tuned tweeter configurations for improved high-frequency clarity
- Included kit: (2) 4" 4Ω coaxial speakers, (2) bass blockers, (6) OEM adaptors, and installation hardware
- Built with larger motor components and durable materials for higher output and reliability
- Technologies noted: CTA-2031, Klippel Verified, ICC Crossover, UV inhibitor materials, Vibration Resistant, COMSOL Multiphysics®, Tru-Sight™
Fit and use
Designed as a simple, all-in-one upgrade for standard factory systems. Common applications include door and rear deck single-speaker locations. Replacing a factory single-cone driver with this 3-way coaxial adds a dedicated tweeter and can noticeably improve clarity and perceived bass ‘punch.’
What to know
Vehicle-specific adapters and the reworked frame geometry improve fit, but confirm mounting depth and speaker location compatibility for your vehicle before purchase. The product kit lists the included components; consult the product reference and advisory resources for fit details and any model-year notices.
Highlights
Key features
- Updated mounting flanges for direct fitment in new vehicles
- 3/4” (19 mm) Tetolon® inverted dome tweeter for reliable performance under stress
- 3/8” (9 mm) Polypropylene piezo super tweeter for enhanced high-frequency response
- 20-40% Mica reinforced Polypropylene curvilinear cone for enhanced rigidity and sonic quality
- Santoprene™ half-roll surround for low distortion and unmatched fatigue resistance
- Co-molded surround and cone body chemically bonded for high durability
- Fatigue and tear resistant linear Nomex® spider
- Ultra-flexible braded tinsel leads securely stitched to spider
- 15% glass-fiber reinforced PA66 injected molded composite basket
- Vented Kapton® voice coil former for excellent heat dissipation
- Overhung voice coil ensures consistent magnetic flux for less speaker distortion
- High strength Y35 ferrite motor structure (5mm larger over previous generation)
Technologies
CTA-2031
Power handling on Rockford Fosgate speakers conform to CTA-2031 industry standards. This means your speaker has
Klippel Verified
To adorn the ‘Verified with Klippel’ mark, the qualifying company’s loudspeaker engineering personnel must be
ICC Crossover
The Integrated Concealed Crossover hides the crossover inside the basket, creating a cleaner look and easier
UV Inhibitor Materials
Centrex and ASA plastic materials are used for their UV radiation resistance and components are tested in
Vibration Resistant
Components are able to withstand shock and vibration conditions common with outdoor vehicles.
COMSOL Multiphysics®
COMSOL software analyzes complex physical phenomena (Multiphysics®) that uses FEM (Finite Element Method) to
Auto Fit Architecture
Everything was engineered to fit. A re-designed frame, mounting holes, removable motor cover and speaker diameter
Tru-Sight™
Tru-Sight™ tweeter ensures precise high-frequency alignment, so every note comes through with clarity and
F.L.W.R.
Our Factory Location Woofer Ring (F.L.W.R.) and mounting flanges provide a flexible yet precise alignment for
Showing the main technologies for this product.
Specs
Specifications
23
| Speaker Type | Coaxial |
| Midrange Size (Nominal Diameter) | 4" |
| Tweeter Size (Nominal Diameter) | 3/4” (19 mm) Inverted Dome |
| Piezo Size (Nominal Diameter) | 3/8” (9 mm) Co-Witnessed Convex |
| Nominal Impedance (Ohms) | 4Ω |
| Frequency Response (Hz) | 75Hz - 25kHz |
| Voice Coil Diameter (in/mm) | 1" (25.4 mm) |
| Crossover | Tweeter High-Pass: 9kHz @ 6 dB/Octave Midrange Bass Blocker: 1,200Hz @ 6 dB/Octave (33µF) |
| Fs (Hz) | 100 Hz |
| Power Handling (Watts RMS) | 75 Watts RMS 150 Watts Peak |
| Sensitivity (dB @ 1W/1M) | 85 dB |
| Sensitivity (2.83V/1M) | 88 dB |
| Cutout Diameter | 3.41" (86.5 mm) |
| Rear-Loading Depth (Twist-Lock Adaptor) | 1.72" (43.8 mm) |
| Front-Loading Depth (Twist-Lock Adaptor) | 1.99" (50.5 mm) |
| Mounting Depth (With Motor Cover) | — |
| Min. Mounting Depth (No Motor Cover) | — |
| Front Side Clearance | 0.5" (12.7 mm) |
| Grille/Trim Ring Included | No |
| Removable Motor Cover | No |
| Included in the Box | (2) 4” 4Ω 3-Way Coaxial Speakers (1) 4” Speaker Cutout Template (2) 4” 4-Tab Twist-Lock Adaptors (2) 4” 3-Tab Twist-Lock Adaptors (2) 4” 3-Tab Wide Twist-Lock Adaptors (2) 33µF Non-Polarized Cap (Bass-Blockers) (8) Self-Tapping Phillips #8x32mm (Speaker) (2) 18 AWG Red/Black Speaker Wire, 205 mm (3) 18 AWG (–) Female Crimp Spade Conn. (.187”) (3) 18 AWG (+) Female Crimp Spade Conn. (.250”) (4) 18 AWG Crimp Butt Connectors |
| Mounting Hardware | Yes |
| Shipping Weight | 3.5 Lbs. (1.59 Kg.) |
What's in the box
| Qty | Part number | Item details |
|---|---|---|
| 2 | — | 4” 4Ω 3-Way Coaxial Speakers |
| 1 | — | 4” Speaker Cutout Template |
| 2 | — | 4” 4-Tab Twist-Lock Adaptors |
| 2 | — | 4” 3-Tab Twist-Lock Adaptors |
| 2 | — | 4” 3-Tab Wide Twist-Lock Adaptors |
| 2 | — | 33µF Non-Polarized Cap (Bass-Blockers) |
| 8 | — | Self-Tapping Phillips #8x32mm (Speaker) |
| 2 | — | 18 AWG Red/Black Speaker Wire, 205 mm |
| 3 | — | 18 AWG (–) Female Crimp Spade Conn. (.187”) |
| 3 | — | 18 AWG (+) Female Crimp Spade Conn. (.250”) |
| 4 | — | 18 AWG Crimp Butt Connectors |
