P1V2-65Punch P1 6.5” 3-Way Coaxial Speaker
Variants
The Punch P1 6.5" 3-way coaxial is an all-in-one upgrade for standard factory systems. It combines a larger motor, precision-tuned tweeter configurations and durable materials to deliver clearer sound and stronger output than typical single-cone factory drivers.
Highlights
- Updated mounting flanges for direct fitment in new vehicles
- 3/4” (19 mm) Tetolon® inverted dome tweeter for reliable performance under stress
- 3/8” (9 mm) Polypropylene piezo super tweeter for enhanced high-frequency response
- 20-40% Mica reinforced Polypropylene curvilinear cone for enhanced rigidity and sonic quality
Key specs
Full specs- Speaker Type
- Coaxial
- Midrange Size (Nominal Diameter)
- 6.5"
- Tweeter Size (Nominal Diameter)
- 3/4” (19 mm) Inverted Dome
- Piezo Size (Nominal Diameter)
- 3/8” (9 mm) Co-Witnessed Convex
- Nominal Impedance (Ohms)
- 4Ω
- Frequency Response (Hz)
- 49Hz - 25kHz
- Voice Coil Diameter (in/mm)
- 1" (25.4 mm)
- Crossover
- Tweeter High-Pass: 9kHz @ 6 dB/Octave
Key specs
Full specs- Speaker Type
- Coaxial
- Midrange Size (Nominal Diameter)
- 6.5"
- Tweeter Size (Nominal Diameter)
- 3/4” (19 mm) Inverted Dome
- Piezo Size (Nominal Diameter)
- 3/8” (9 mm) Co-Witnessed Convex
Highlights
Overview- Updated mounting flanges for direct fitment in new vehicles
- 3/4” (19 mm) Tetolon® inverted dome tweeter for reliable performance under stress
- 3/8” (9 mm) Polypropylene piezo super tweeter for enhanced high-frequency response
Overview
The Punch P1 6.5" 3-way coaxial is an all-in-one upgrade for standard factory systems. It combines a larger motor, precision-tuned tweeter configurations and durable materials to deliver clearer sound and stronger output than typical single-cone factory drivers.
Best for
- Basic OEM system upgrades
- Vehicles with single-speaker locations in doors or rear decks
- Users seeking a simple drop-in replacement for improved clarity and punch
Key points
- Auto Fit Architecture with redesigned frame geometry for seamless integration
- Factory Location Woofer Ring (F.L.W.R.) and mounting flanges for flexible alignment
- 3-way coaxial design adds a precision-tuned tweeter for clearer highs
- Larger motor and durable materials for sustained output and reliability
- Technologies and verification: CTA-2031, Klippel Verified, ICC Crossover, COMSOL Multiphysics®, Tru-Sight™, UV inhibitor and vibration-resistant materials
Fit and use
Engineered for drop-in integration into many factory mounting locations. Features include a redesigned frame, mounting holes, removable motor cover, and mounting flanges to aid alignment with OEM openings. Intended as a straightforward speaker upgrade to replace factory single-cone drivers; follow vehicle- and speaker-specific installation guidance from the installer or manufacturer.
What to know
Sold as a matched pair with installation hardware noted in the product overview. Designed to work as a direct-improvement option for factory systems rather than a full custom audio overhaul. Performance and fit depend on vehicle speaker locations and mounting depth—confirm compatibility with your vehicle before purcha…
Highlights
Key features
- Updated mounting flanges for direct fitment in new vehicles
- 3/4” (19 mm) Tetolon® inverted dome tweeter for reliable performance under stress
- 3/8” (9 mm) Polypropylene piezo super tweeter for enhanced high-frequency response
- 20-40% Mica reinforced Polypropylene curvilinear cone for enhanced rigidity and sonic quality
- Santoprene™ half-roll surround for low distortion and unmatched fatigue resistance
- Co-molded surround and cone body chemically bonded for high durability
- Fatigue and tear resistant linear Nomex® spider
- Ultra-flexible braded tinsel leads securely stitched to spider
- 15% glass-fiber reinforced PA66 injected molded composite basket
- Vented Kapton® voice coil former for excellent heat dissipation
- Overhung voice coil ensures consistent magnetic flux for less speaker distortion
- High strength Y35 ferrite motor structure (5mm larger over previous generation)
Technologies
CTA-2031
Power handling on Rockford Fosgate speakers conform to CTA-2031 industry standards. This means your speaker has
Klippel Verified
To adorn the ‘Verified with Klippel’ mark, the qualifying company’s loudspeaker engineering personnel must be
ICC Crossover
The Integrated Concealed Crossover hides the crossover inside the basket, creating a cleaner look and easier
UV Inhibitor Materials
Centrex and ASA plastic materials are used for their UV radiation resistance and components are tested in
Vibration Resistant
Components are able to withstand shock and vibration conditions common with outdoor vehicles.
COMSOL Multiphysics®
COMSOL software analyzes complex physical phenomena (Multiphysics®) that uses FEM (Finite Element Method) to
Auto Fit Architecture
Everything was engineered to fit. A re-designed frame, mounting holes, removable motor cover and speaker diameter
Tru-Sight™
Tru-Sight™ tweeter ensures precise high-frequency alignment, so every note comes through with clarity and
VAST 2.0™
The Vertical Attach Surround Technique delivers a 25% increase in cone area, resulting in maximum output and
Showing the main technologies for this product.
Specs
Specifications
23
| Speaker Type | Coaxial |
| Midrange Size (Nominal Diameter) | 6.5" |
| Tweeter Size (Nominal Diameter) | 3/4” (19 mm) Inverted Dome |
| Piezo Size (Nominal Diameter) | 3/8” (9 mm) Co-Witnessed Convex |
| Nominal Impedance (Ohms) | 4Ω |
| Frequency Response (Hz) | 49Hz - 25kHz |
| Voice Coil Diameter (in/mm) | 1" (25.4 mm) |
| Crossover | Tweeter High-Pass: 9kHz @ 6 dB/Octave |
| Fs (Hz) | 65 Hz |
| Power Handling (Watts RMS) | 75 Watts RMS 150 Watts Peak |
| Sensitivity (2.83V/1M) | 91 dB |
| Sensitivity (dB @ 1W/1M) | 88 dB |
| Cutout Diameter | 5.42" (137.6 mm) |
| Rear-Loading Depth (Twist-Lock Adaptor) | — |
| Front-Loading Depth (Twist-Lock Adaptor) | — |
| Mounting Depth (With Motor Cover) | 2.5" (63.5 mm) |
| Min. Mounting Depth (No Motor Cover) | 2.26" (57.3 mm) |
| Front Side Clearance | 0.43" (11 mm) |
| Removable Motor Cover | Yes |
| Grille/Trim Ring Included | No |
| Included in the Box | (2) 6.50” 4Ω 3-Way Coaxial Speakers (1) 6.50” Speaker Cutout Template (8) Self-Tapping Phillips #8x32mm (Speaker) (2) 18 AWG Red/Black Speaker Wire, 205 mm (3) 18 AWG (–) Female Crimp Spade Conn. (.187”) (3) 18 AWG (+) Female Crimp Spade Conn. (.250”) (4) 18 AWG Crimp Butt Connectors |
| Mounting Hardware | Yes |
| Shipping Weight | 5 Lbs. (2.27 Kg.) |
What's in the box
| Qty | Part number | Item details |
|---|---|---|
| 2 | — | 6.50” 4Ω 3-Way Coaxial Speakers |
| 1 | — | 6.50” Speaker Cutout Template |
| 8 | — | Self-Tapping Phillips #8x32mm (Speaker) |
| 2 | — | 18 AWG Red/Black Speaker Wire, 205 mm |
| 3 | — | 18 AWG (–) Female Crimp Spade Conn. (.187”) |
| 3 | — | 18 AWG (+) Female Crimp Spade Conn. (.250”) |
| 4 | — | 18 AWG Crimp Butt Connectors |
