P1V2-5Punch P1 5.25” 3-Way Coaxial Speaker
Variants
The Punch P1 5.25" 3-way coaxial speaker is an all-in-one upgrade for standard factory car audio systems. It combines a larger motor, precision-tuned tweeter configurations, and durable materials to deliver clearer, punchier sound in doors or rear decks.
Highlights
- Updated mounting flanges for direct fitment in new vehicles
- 3/4” (19 mm) Tetolon® inverted dome tweeter for reliable performance under stress
- 3/8” (9 mm) Polypropylene piezo super tweeter for enhanced high-frequency response
- 20-40% Mica reinforced Polypropylene curvilinear cone for enhanced rigidity and sonic quality
Key specs
Full specs- Speaker Type
- Coaxial
- Midrange Size (Nominal Diameter)
- 5.25"
- Tweeter Size (Nominal Diameter)
- 3/4” (19 mm) Inverted Dome
- Piezo Size (Nominal Diameter)
- 3/8” (9 mm) Co-Witnessed Convex
- Nominal Impedance (Ohms)
- 4Ω
- Frequency Response (Hz)
- 56Hz - 25kHz
- Voice Coil Diameter (in/mm)
- 1" (25.4 mm)
- Crossover
- Tweeter High-Pass: 9kHz @ 6 dB/Octave
Key specs
Full specs- Speaker Type
- Coaxial
- Midrange Size (Nominal Diameter)
- 5.25"
- Tweeter Size (Nominal Diameter)
- 3/4” (19 mm) Inverted Dome
- Piezo Size (Nominal Diameter)
- 3/8” (9 mm) Co-Witnessed Convex
Highlights
Overview- Updated mounting flanges for direct fitment in new vehicles
- 3/4” (19 mm) Tetolon® inverted dome tweeter for reliable performance under stress
- 3/8” (9 mm) Polypropylene piezo super tweeter for enhanced high-frequency response
Overview
The Punch P1 5.25" 3-way coaxial speaker is an all-in-one upgrade for standard factory car audio systems. It combines a larger motor, precision-tuned tweeter configurations, and durable materials to deliver clearer, punchier sound in doors or rear decks.
Best for
- Drivers who want a straightforward drop-in upgrade to single-cone factory speakers to gain improved high-frequency clar…
Key points
- Auto Fit Architecture: redesigned frame geometry, mounting holes and removable motor cover for seamless integration into modern factory locations.
- Precision-tuned tweeter configurations for improved clarity over single-cone OEM drivers.
- Larger motor and durable materials for higher output and long-term reliability.
- Factory Location Woofer Ring (F.L.W.R.) and mounting flanges to aid drop-in alignment.
- Technologies listed: CTA-2031, Klippel Verified, ICC Crossover, UV inhibitor materials, vibration resistance, COMSOL Multiphysics®, Tru-Sight™.
Fit and use
Designed as a simple, all-in-one upgrade for factory single-speaker locations such as door panels or rear decks. Vehicle-specific adapters and the redesigned frame help the speaker integrate into many modern mounting locations. Intended to replace single-cone drivers with a 3-way coaxial to add a dedicated tweeter for improved sound clarity.
What to know
This product is part of the P1 PUNCH series and is engineered to fit many factory locations using provided adapters and frame features. Kit information provided with the source lists: (2) 5.25" 4Ω coaxial speakers, (4) OEM adaptors, and installation hardware. Refer to manufacturer resources for details on fitment and…
Highlights
Key features
- Updated mounting flanges for direct fitment in new vehicles
- 3/4” (19 mm) Tetolon® inverted dome tweeter for reliable performance under stress
- 3/8” (9 mm) Polypropylene piezo super tweeter for enhanced high-frequency response
- 20-40% Mica reinforced Polypropylene curvilinear cone for enhanced rigidity and sonic quality
- Santoprene™ half-roll surround for low distortion and unmatched fatigue resistance
- Co-molded surround and cone body chemically bonded for high durability
- Fatigue and tear resistant linear Nomex® spider
- Ultra-flexible braded tinsel leads securely stitched to spider
- 15% glass-fiber reinforced PA66 injected molded composite basket
- Vented Kapton® voice coil former for excellent heat dissipation
- Overhung voice coil ensures consistent magnetic flux for less speaker distortion
- High strength Y35 ferrite motor structure (5mm larger over previous generation)
Technologies
CTA-2031
Power handling on Rockford Fosgate speakers conform to CTA-2031 industry standards. This means your speaker has
Klippel Verified
To adorn the ‘Verified with Klippel’ mark, the qualifying company’s loudspeaker engineering personnel must be
ICC Crossover
The Integrated Concealed Crossover hides the crossover inside the basket, creating a cleaner look and easier
UV Inhibitor Materials
Centrex and ASA plastic materials are used for their UV radiation resistance and components are tested in
Vibration Resistant
Components are able to withstand shock and vibration conditions common with outdoor vehicles.
COMSOL Multiphysics®
COMSOL software analyzes complex physical phenomena (Multiphysics®) that uses FEM (Finite Element Method) to
Auto Fit Architecture
Everything was engineered to fit. A re-designed frame, mounting holes, removable motor cover and speaker diameter
Tru-Sight™
Tru-Sight™ tweeter ensures precise high-frequency alignment, so every note comes through with clarity and
F.L.W.R.
Our Factory Location Woofer Ring (F.L.W.R.) and mounting flanges provide a flexible yet precise alignment for
Showing the main technologies for this product.
Specs
Specifications
23
| Speaker Type | Coaxial |
| Midrange Size (Nominal Diameter) | 5.25" |
| Tweeter Size (Nominal Diameter) | 3/4” (19 mm) Inverted Dome |
| Piezo Size (Nominal Diameter) | 3/8” (9 mm) Co-Witnessed Convex |
| Nominal Impedance (Ohms) | 4Ω |
| Frequency Response (Hz) | 56Hz - 25kHz |
| Voice Coil Diameter (in/mm) | 1" (25.4 mm) |
| Crossover | Tweeter High-Pass: 9kHz @ 6 dB/Octave |
| Fs (Hz) | 75 Hz |
| Power Handling (Watts RMS) | 75 Watts RMS 150 Watts Peak |
| Sensitivity (dB @ 1W/1M) | 86 dB |
| Sensitivity (2.83V/1M) | 89 dB |
| Cutout Diameter | 4.37" (111 mm) |
| Rear-Loading Depth (Twist-Lock Adaptor) | 2.33" (59.2 mm) |
| Front-Loading Depth (Twist-Lock Adaptor) | 2.60" (66 mm) |
| Mounting Depth (With Motor Cover) | — |
| Min. Mounting Depth (No Motor Cover) | 2.31" (58.6 mm) |
| Front Side Clearance | 0.44" (11.1 mm) |
| Removable Motor Cover | Yes |
| Grille/Trim Ring Included | No |
| Included in the Box | (2) 5.25” 4Ω 3-Way Coaxial Speakers (1) 5.25” Speaker Cutout Template (2) 5.25” 4-Tab Twist-Lock Adaptors (2) 5.25” to 4x6” Adaptors (2) 5.25” 3-Tab Wide Adaptors (2) 5.25” 3-Tab Wide Adaptors (8) Self-Tapping Phillips #8x32mm (Speaker) (2) 18 AWG Red/Black Speaker Wire, 205 mm (3) 18 AWG (–) Female Crimp Spade Conn. (.187”) (3) 18 AWG (+) Female Crimp Spade Conn. (.250”) (4) 18 AWG Crimp Butt Connectors |
| Mounting Hardware | Yes |
| Shipping Weight | 5 Lbs. (2.27 Kg.) |
What's in the box
| Qty | Part number | Item details |
|---|---|---|
| 2 | — | 5.25” 4Ω 3-Way Coaxial Speakers |
| 1 | — | 5.25” Speaker Cutout Template |
| 2 | — | 5.25” 4-Tab Twist-Lock Adaptors |
| 2 | — | 5.25” to 4x6” Adaptors |
| 2 | — | 5.25” 3-Tab Wide Adaptors |
| 2 | — | 5.25” 3-Tab Wide Adaptors |
| 8 | — | Self-Tapping Phillips #8x32mm (Speaker) |
| 2 | — | 18 AWG Red/Black Speaker Wire, 205 mm |
| 3 | — | 18 AWG (–) Female Crimp Spade Conn. (.187”) |
| 3 | — | 18 AWG (+) Female Crimp Spade Conn. (.250”) |
| 4 | — | 18 AWG Crimp Butt Connectors |
