P1V2-69Punch P1 6"x9” 3-Way Coaxial Speaker
Variants
The Punch P1 6x9 3-way coaxial speaker is an all-in-one upgrade for standard factory systems. It pairs a precision-tuned tweeter with a larger motor and durable materials to deliver clearer highs and improved overall output.
Highlights
- Updated mounting flanges for direct fitment in new vehicles
- 3/4” (19 mm) Tetolon® inverted dome tweeter for reliable performance under stress
- 3/8” (9 mm) Polypropylene piezo super tweeter for enhanced high-frequency response
- 20-40% Mica reinforced Polypropylene curvilinear cone for enhanced rigidity and sonic quality
Key specs
Full specs- Speaker Type
- Coaxial
- Midrange Size (Nominal Diameter)
- 6"x9"
- Tweeter Size (Nominal Diameter)
- 3/4” (19 mm) Inverted Dome
- Piezo Size (Nominal Diameter)
- 3/8” (9 mm) Co-Witnessed Convex
- Nominal Impedance (Ohms)
- 4Ω
- Frequency Response (Hz)
- 45Hz - 25kHz
- Voice Coil Diameter (in/mm)
- 1" (25.4 mm)
- Crossover
- Tweeter High-Pass: 9kHz @ 6 dB/Octave
Key specs
Full specs- Speaker Type
- Coaxial
- Midrange Size (Nominal Diameter)
- 6"x9"
- Tweeter Size (Nominal Diameter)
- 3/4” (19 mm) Inverted Dome
- Piezo Size (Nominal Diameter)
- 3/8” (9 mm) Co-Witnessed Convex
Highlights
Overview- Updated mounting flanges for direct fitment in new vehicles
- 3/4” (19 mm) Tetolon® inverted dome tweeter for reliable performance under stress
- 3/8” (9 mm) Polypropylene piezo super tweeter for enhanced high-frequency response
Overview
The Punch P1 6x9 3-way coaxial speaker is an all-in-one upgrade for standard factory systems. It pairs a precision-tuned tweeter with a larger motor and durable materials to deliver clearer highs and improved overall output.
Best for
- Upgrading basic OEM systems with single-cone drivers
- Door or rear-deck speaker locations in many vehicles
- Listeners seeking clearer highs and more punch without adding separate components
Key points
- 3-way coaxial design adds a dedicated tweeter for improved clarity
- Engineered Auto Fit Architecture for seamless integration into many factory locations
- 4Ω impedance
- Larger motor for increased output
- Precision-tuned tweeter configurations
- Durable materials with UV inhibitor and vibration resistance
Fit and use
Designed with a reworked frame, mounting holes, removable motor cover, Factory Location Woofer Ring (F.L.W.R.) and mounting flanges to support drop-in integration into many factory mounting locations. Intended as a direct 3-way coaxial replacement to improve clarity and dynamics where single-cone factory drivers are used.
What to know
This product is supplied as a pair of 6x9 4Ω coaxial speakers with installation hardware noted in the source. Vehicle-specific fitment can vary—confirm physical clearance and mounting compatibility with your vehicle before purchase. Detailed performance specs (power handling, frequency response) should be checked in t…
Highlights
Key features
- Updated mounting flanges for direct fitment in new vehicles
- 3/4” (19 mm) Tetolon® inverted dome tweeter for reliable performance under stress
- 3/8” (9 mm) Polypropylene piezo super tweeter for enhanced high-frequency response
- 20-40% Mica reinforced Polypropylene curvilinear cone for enhanced rigidity and sonic quality
- Santoprene™ half-roll surround for low distortion and unmatched fatigue resistance
- Co-molded surround and cone body chemically bonded for high durability
- Fatigue and tear resistant linear Nomex® spider
- Ultra-flexible braded tinsel leads securely stitched to spider
- 15% glass-fiber reinforced PA66 injected molded composite basket
- Vented Kapton® voice coil former for excellent heat dissipation
- Overhung voice coil ensures consistent magnetic flux for less speaker distortion
- High strength Y35 ferrite motor structure (5mm larger over previous generation)
Technologies
CTA-2031
Power handling on Rockford Fosgate speakers conform to CTA-2031 industry standards. This means your speaker has
Klippel Verified
To adorn the ‘Verified with Klippel’ mark, the qualifying company’s loudspeaker engineering personnel must be
ICC Crossover
The Integrated Concealed Crossover hides the crossover inside the basket, creating a cleaner look and easier
UV Inhibitor Materials
Centrex and ASA plastic materials are used for their UV radiation resistance and components are tested in
Vibration Resistant
Components are able to withstand shock and vibration conditions common with outdoor vehicles.
COMSOL Multiphysics®
COMSOL software analyzes complex physical phenomena (Multiphysics®) that uses FEM (Finite Element Method) to
Auto Fit Architecture
Everything was engineered to fit. A re-designed frame, mounting holes, removable motor cover and speaker diameter
Tru-Sight™
Tru-Sight™ tweeter ensures precise high-frequency alignment, so every note comes through with clarity and
VAST 2.0™
The Vertical Attach Surround Technique delivers a 25% increase in cone area, resulting in maximum output and
Showing the main technologies for this product.
Specs
Specifications
23
| Speaker Type | Coaxial |
| Midrange Size (Nominal Diameter) | 6"x9" |
| Tweeter Size (Nominal Diameter) | 3/4” (19 mm) Inverted Dome |
| Piezo Size (Nominal Diameter) | 3/8” (9 mm) Co-Witnessed Convex |
| Nominal Impedance (Ohms) | 4Ω |
| Frequency Response (Hz) | 45Hz - 25kHz |
| Voice Coil Diameter (in/mm) | 1" (25.4 mm) |
| Crossover | Tweeter High-Pass: 9kHz @ 6 dB/Octave |
| Power Handling (Watts RMS) | 75 Watts RMS 150 Watts Peak |
| Fs | 60 Hz |
| Sensitivity (dB @ 1W/1M) | 89 dB |
| Sensitivity (2.83V/1M) | 92 dB |
| Cutout Diameter | 8.4" x 5.71" (213.5 mm x 145 mm) |
| Rear-Loading Depth (Twist-Lock Adaptor) | — |
| Front-Loading Depth (Twist-Lock Adaptor) | — |
| Mounting Depth (With Motor Cover) | 3.13" (79.4 mm) |
| Min. Mounting Depth (No Motor Cover) | 3.13" (70 mm) |
| Front Side Clearance | 0.42" (10.6 mm) |
| Removable Motor Cover | Yes |
| Grille/Trim Ring Included | No |
| Included in the Box | (2) 6”x9” 4Ω 3-Way Coaxial Speakers (1) 6”x9” Speaker Cutout Template (8) Self-Tapping Phillips #8x32mm (Speaker) (2) 18 AWG Red/Black Speaker Wire, 205 mm (3) 18 AWG (–) Female Crimp Spade Conn. (.187”) (3) 18 AWG (+) Female Crimp Spade Conn. (.250”) (4) 18 AWG Crimp Butt Connectors |
| Mounting Hardware | Yes |
| Shipping Weight | 7 Lbs. (3.18 Kg.) |
What's in the box
| Qty | Part number | Item details |
|---|---|---|
| 2 | — | 6”x9” 4Ω 3-Way Coaxial Speakers |
| 1 | — | 6”x9” Speaker Cutout Template |
| 8 | — | Self-Tapping Phillips #8x32mm (Speaker) |
| 2 | — | 18 AWG Red/Black Speaker Wire, 205 mm |
| 3 | — | 18 AWG (–) Female Crimp Spade Conn. (.187”) |
| 3 | — | 18 AWG (+) Female Crimp Spade Conn. (.250”) |
| 4 | — | 18 AWG Crimp Butt Connectors |
